Allen-Bradley 150-F251NBD PowerFlex 755TL AC Drive

The Allen-Bradley 150-F251NBD is a PowerFlex 755TL AC drive designed for high-performance motor control in demanding industrial applications. This advanced drive features a transformerless (TL) design with active front-end technology, providing clean power characteristics and regenerative braking capability. Part of Rockwell Automation's flagship PowerFlex 755 series, this drive delivers superior performance for applications requiring precise speed and torque control.

• Active Front End (AFE) Technology - Low harmonic distortion and regenerative capability
• Transformerless Design - Compact footprint with reduced installation costs
• Common Bus Configuration - Suitable for multi-drive systems
• Advanced Control - Flux vector control for high-performance applications
• Integrated Safety - Built-in safety functions (option dependent)
• Industrial Connectivity - Multiple communication protocol options
• High Efficiency - Optimized performance with reduced energy consumption

• Overload Capacity - 110% of rated current for 60 seconds
• Efficiency - >98% typical
• Total Harmonic Distortion - <5% (IEEE 519 compliant)
• Power Factor - >0.98 throughout speed range
• Regenerative Capability - 100% regenerative power capability

• Speed Regulation - ±0.001% of base speed (encoder feedback)
• Speed Range - 2000:1 speed range (encoderless)
• Torque Response - <5 ms typical
• Starting Torque - 200% at 0 rpm

• Embedded Options - EtherNet/IP, DeviceNet, ControlNet
• Protocol Support - CIP, Modbus TCP, PROFIBUS, PROFINET
• I/O Capacity - Extensive digital and analog I/O options
• Programming - Connected Components Workbench (CCW)

• Studio 5000 Integration - Seamless integration with Logix platform
• Data Logging - Built-in data recording capability
• Web Server - Embedded web pages for monitoring
• Energy Monitoring - Real-time power consumption tracking

• Enclosure Material - Heavy-gauge steel construction
• Cooling Method - Fan-cooled with air filtration
• Coating - Corrosion-resistant finish
• Mounting - Wall-mounted or floor-standing options

• Protection Rating - IP20 (NEMA Type 1 standard)
• Altitude Rating - Up to 1000m without derating
• Relative Humidity - 5% to 95% non-condensing
• Vibration Resistance - 1.0 G (5-2000 Hz)

The PowerFlex 755TL is ideal for:

• High-Performance Machinery - Precision manufacturing equipment
• Material Handling - Cranes, hoists, and conveyor systems
• Test Stands - Dynamic testing applications
• Extruders - Plastic and rubber processing
• Centrifuges - High-speed separation equipment
• Winders - Paper, film, and textile applications

• Input Power - 3-Phase, 380-480V AC (±10%)
• DC Bus Voltage - 510-680V DC
• Short Circuit Rating - 65kA IC symmetrical
• Grounding - Proper grounding required for EMI immunity

• Clearance Requirements - Minimum 100mm top/bottom, 50mm sides
• Ventilation - Adequate airflow for heat dissipation
• Ambient Temperature - 0°C to +40°C (derating above 40°C)
• Pollution Degree - Degree 2 per IEC 61800-5-1

• Quality Standards - ISO 9001 manufacturing
• EMC Compliance - IEC 61800-3, EN 61800-3
• Environmental - RoHS compliant
• Industry Standards - UL, cUL, CE marked

• Clean Power - Low harmonic distortion with active front end
• Energy Efficient - Regenerative capability reduces energy costs
• High Performance - Superior control for demanding applications
• System Integration - Seamless integration with Allen-Bradley architecture
• Reliability - Industrial-grade construction for continuous operation
• Flexibility - Multiple configuration options for various applications
