Product Overview

The ​SICK KTM-WN11172P​ is an advanced photoelectric sensor designed for precise object detection and positioning in industrial automation applications. This high-performance sensor utilizes infrared light technology to provide reliable detection across various industrial environments, offering exceptional accuracy and durability for demanding automation tasks.

Key Features

• ​High Precision Detection​ - Accurate object detection with precise positioning capabilities

• ​Infrared Light Technology​ - 880nm wavelength for reliable operation in various conditions

• ​Long Sensing Distance​ - Extended detection range for flexible application use

• ​NPN Output Configuration​ - Standard industrial output for easy integration

• ​IP67 Protection Rating​ - Dust-tight and waterproof construction for harsh environments

• ​LED Status Indicators​ - Visual operation and status monitoring

• ​Compact Design​ - Space-efficient housing for easy installation

• ​Temperature Resistant​ - Stable performance across wide operating temperatures

Technical Specifications

Electrical Characteristics

Output Specifications

• ​Output Current​ - 100mA maximum

• ​Voltage Drop​ - ≤2.0V at 100mA

• ​Residual Current​ - ≤0.1mA

• ​Short-Circuit Protection​ - Built-in, auto-reset

Electrical Connections

• ​Brown Wire​ - +V DC (10-30V)

• ​Blue Wire​ - 0V DC (Ground)

• ​Black Wire​ - Output signal (NPN)

• ​Shield​ - Cable shielding (connected to housing)

Performance Characteristics

Optical Performance

• ​Light Source​ - Infrared LED with 880nm wavelength

• ​Beam Characteristics​ - Parallel light beam with minimal divergence

• ​Ambient Light Immunity​ - Resistant to up to 10,000 Lux

• ​Response Time​ - Fast 1ms response for high-speed applications

Environmental Specifications

• ​Ingress Protection​ - IP67 rated (dust-tight and waterproof)

• ​Shock Resistance​ - 1000m/s² (6ms duration)

• ​Vibration Resistance​ - 10-55Hz, 1.5mm amplitude

• ​EMC Compatibility​ - EN 60947-5-2

Applications

The SICK KTM-WN11172P is ideal for:

• ​Conveyor Systems​ - Object detection and counting on production lines

• ​Packaging Machinery​ - Product presence verification and positioning

• ​Material Handling​ - Position detection in automated storage systems

• ​Automated Assembly​ - Component presence checking in assembly lines

• ​Robotic Systems​ - Object detection for robotic manipulation

• ​Industrial Automation​ - General purpose object detection

• ​Logistics Systems​ - Package detection and sorting applications

Installation & Operation

Mounting Requirements

• ​Mounting​ - Bracket mounting with adjustable brackets

• ​Alignment​ - Precise optical alignment required

• ​Orientation​ - Any mounting position supported

• ​Clearance​ - Minimum 50mm from reflective surfaces

Electrical Installation

• ​Wiring​ - Standard 3-wire connection

• ​Polarity Protection​ - Reverse polarity protected

• ​Load Connection​ - Connect between output and ground

• ​Cable Length​ - 2m standard length

Operation Indicators

• ​Power LED​ - Green LED indicates power status

• ​Signal LED​ - Yellow LED indicates output state

• ​Alignment Aid​ - LED indicators for beam alignment

Certifications & Compliance

• ​Safety Standards:

  • EN 60947-5-2

  • IEC 60947-5-2

• ​EMC Compliance:

  • EN 60947-5-2

  • EMI Immunity: 20V/m

• ​Environmental Standards:

  • IP67 protection rating

  • RoHS compliant

  • REACH compliant

• ​Quality Standards:

  • ISO 9001 manufacturing

Why Choose SICK KTM-WN11172P?

• ​High Accuracy​ - Precise detection capabilities for critical applications

• ​Reliable Performance​ - Consistent operation in various industrial environments

• ​Robust Construction​ - Durable housing for long service life

• ​Easy Integration​ - Standard electrical connections and mounting

• ​Maintenance-Free​ - No moving parts for reliable operation

• ​Global Support​ - Backed by SICK's worldwide technical network

• ​Quality Assurance​ - German engineering and manufacturing excellence

Maintenance & Service

• ​Lens Cleaning​ - Regular cleaning of optical window recommended

• ​Visual Inspection​ - Periodic check for physical damage

• ​Functional Testing​ - Regular verification of detection performance

• ​Alignment Check​ - Periodic verification of beam alignment

• ​Technical Support​ - Comprehensive documentation and support available

Note: Specifications are based on standard testing conditions. Actual performance may vary based on environmental factors and target object properties. Consult SICK technical documentation for detailed application guidelines.
