Product: Pepperl+Fuchs NJ5-18GM-N Inductive Proximity Sensor

The Pepperl+Fuchs NJ5-18GM-N is a standard-duty, cylindrical inductive proximity sensor designed for the non-contact detection of metallic objects. It is a reliable and cost-effective solution for common position sensing tasks in industrial environments.

Key Features

• Robust Metal Housing:​ Nickel-plated brass barrel for mechanical durability.

• Non-Contact Sensing:​ Wear-free detection of ferrous and non-ferrous metals.

• Embedded LED:​ Status LED for visual indication of switching state.

• Short-Circuit Protection:​ Built-in protection against wiring errors.

Technical Specifications

• Part Number:​ NJ5-18GM-N

• Sensor Type:​ Inductive, Cylindrical

• Sensing Distance (Sn):​ 18 mm

• Switch Point:​ ≤ 90% of Sn (for standard steel)

• Hysteresis:​ ≤ 15% of Sn

• Output Type:​ 3-Wire DC, NPN

• Output Function:​ Normally Open (NO)

• Supply Voltage:​ 10 ... 30 V DC

• Max. Switching Current:​ 200 mA

• Switching Frequency:​ 100 Hz

• Electrical Connection:​ 2m PVC cable

• Housing Material:​ Nickel-plated brass

• Face Material:​ PBT

• Protection Rating:​ IP67

• Temperature Range:​ -25 ... 70 °C

Order Code Breakdown

• NJ5:​ Series

• -18:​ Sensing Distance (18mm)

• GM:​ Housing Size (M30)

• -N:​ Output Configuration (NPN, Normally Open, 2m cable)

Typical Applications

This sensor is widely used for detecting the presence or position of metal parts in:

• Machine tooling and automation

• Conveyor systems

• Material handling equipment

• Packaging machinery

Important Note

This is an NPN (sinking) output, normally open (NO)​ sensor. In the NO configuration, the output switches to 0V (ground) when a target is detected. Ensure this output type is compatible with your PLC or controller input module. For a PNP (sourcing) or normally closed (NC) version, a different part number is required.

Note: Specifications are for product identification and comparison. For detailed mounting clearances and temperature curves, consult the official Pepperl+Fuchs NJ5 series datasheet.
