Siemens 7MH7144-1AA2 Level Transmitter | Radar, 80GHz, 10m Range Specs
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Sensing Range: | 20 Mm ... 2000 Mm (adjustable) | Housing Material: | Plastic (PBT) |
|---|---|---|---|
| Connection Type: | M12 4-pin Plug | Protection Rating: | IP67 |
| Operating Temperature: | -25 °C ... +55 °C | Approvals / Standards: | CE, RoHS |
| Highlight: | Siemens 7MH7144-1AA2 radar level transmitter,80GHz radar level sensor,10m range level transmitter |
||
Siemens 7MH7144-1AA2 Level Transmitter | Radar, 80GHz, 10m Range Specs
Siemens 7MH7144-1AA2 SITRANS LR560 radar level transmitter. 80GHz, 10m range, 4-20mA/HART, 2-wire. For liquids and solids.
Product: Siemens 7MH7144-1AA2 Radar Level Transmitter (SITRANS LR560)
The Siemens 7MH7144-1AA2 is a 80 GHz frequency-modulated continuous wave (FMCW) radar level transmitter from the SITRANS LR560 series. It is designed for highly accurate, non-contact continuous level measurement of liquids and solids, even in challenging conditions with dust, foam, or vapors.
Key Features
-
80 GHz Frequency: Provides a focused beam for improved performance on small vessels, agitators, and in noisy environments.
-
High Accuracy: Exceptional measurement accuracy, typically within ±2 mm.
-
Two-Wire Technology: Simple 4-20 mA with HART 7 communication for easy integration.
-
Robust Design: Suitable for a wide range of process temperatures and pressures.
Technical Specifications
-
Order Number: 7MH7144-1AA2
-
Product Family: SITRANS LR560
-
Measuring Principle: 80 GHz FMCW Radar
-
Measuring Range: Up to 10 meters (32.8 ft)
-
Process Connection: Threaded G1½ A / 1½" NPT (specific to this variant)
-
Antenna Type & Size: Cone antenna, 40 mm diameter
-
Process Temperature: -40 to 200 °C (-40 to 392 °F)
-
Process Pressure: -1 to 40 bar (-14.5 to 580 psi)
-
Signal Output: 4-20 mA with HART
-
Power Supply: 12 to 30 V DC (two-wire)
-
Accuracy: Typically ≤ ±2 mm
-
Display/Operation: Integrated four-line graphic display with pushbuttons
-
Housing Protection: IP66 / IP67 / Type 4X
-
Housing Material: Aluminum, epoxy-coated
-
Safety Approvals: FM, FMc, ATEX, IECEx, SIL 2/3 capable
Typical Applications
This radar transmitter is ideal for continuous level measurement in:
-
Chemical and pharmaceutical storage tanks
-
Water and wastewater level control
-
Food and beverage industry vessels
-
Plastics and bulk solids silos
Important Note
The suffix 1AA2 defines the specific configuration, including the G1½ / 1½" NPT process connection. Always verify the exact antenna type, process seal material (e.g., FKM), and approvals for your application. Configuration is performed via the local display or SIMATIC PDM software.
Note: Specifications are for product identification and comparison. For detailed sizing, safety, and configuration data, consult the official Siemens SITRANS LR560 operating instructions and data sheet.
