Product Overview

The MTL 4549​ is an advanced fieldbus power supply with Ethernet diagnostics​ from MTL's 4500 series, designed to provide regulated power, signal conditioning, and comprehensive diagnostic monitoring​ for FOUNDATION Fieldbus H1 and PROFIBUS PA networks. This device delivers 350 mA of fieldbus power, features an integrated Ethernet interface for web-based diagnostics, provides advanced protection features, and carries ATEX and IECEx approvals​ for Zone 1 hazardous area installations. The 4549 represents the latest generation of intelligent fieldbus power supplies with network connectivity.

Technical Specifications

Note: Specifications are based on MTL 4500 series documentation. The 4549 includes advanced Ethernet connectivity for remote management. Always verify with the latest product datasheet.

Key Features

• Ethernet Connectivity:​ 10/100 Mbps interface for remote access and integration

• Web-Based Interface:​ Configuration and monitoring via standard web browser

• Advanced Diagnostics:​ Comprehensive real-time and historical monitoring

• Modbus TCP Support:​ Integration with SCADA, DCS, and asset management systems

• Software Configurable:​ All parameters adjustable via software interface

• Intrinsic Safety:​ Approved for Zone 1 hazardous locations

• Data Logging:​ Historical trend recording for predictive maintenance

• Alarm Notification:​ Configurable email/SMS alerts for fault conditions

• Security Features:​ User authentication and access control

• Global Approvals:​ Certified for international hazardous area applications

Web Interface Capabilities

Network Protocols Supported

Electrical Characteristics

Entity Parameters (for Hazardous Area Design)

Note: The 4549 is an associated apparatus. All connected fieldbus devices must be intrinsically safe certified.

Typical Network Integration

[Plant Network]
       |
[MTL 4549 - Ethernet]
       |
[Fieldbus H1/PA Segment]
       |
[Field Devices: Transmitters, Valves, etc.]

Typical Applications

• Modern Process Plants:​ Fieldbus networks requiring integration with plant information systems

• Remote Monitoring Facilities:​ Sites requiring off-site diagnostic access

• Predictive Maintenance Programs:​ Facilities using data analytics for maintenance planning

• Integrated Control Systems:​ Plants with SCADA/DCS systems using Modbus TCP

• Large-Scale Deployments:​ Multiple units manageable from central location

• Regulated Industries:​ Facilities requiring audit trails and diagnostic records

• Safety Systems:​ SIL 2 applications with advanced diagnostic requirements

• Brownfield Upgrades:​ Modernizing existing fieldbus infrastructure with network capabilities

Important Technical Notes

1. Network Security:​ The Ethernet interface presents cybersecurity considerations. Implement network segmentation, firewalls, and access controls per IEC 62443/ISA-99 standards.

2. IP Configuration:​ Supports both DHCP and static IP addressing. Plan IP addresses as part of network design.

3. Power Supply Requirements:​ Requires 20-30V DC input. Recommended: 24V DC, 1A capacity to support both fieldbus and Ethernet functions.

4. Configuration Backup:​ Regularly backup configuration settings. The web interface allows configuration export/import.

5. Certification Compliance:​ Verify that the 4549's certifications match the hazardous area classification of your installation.

6. Thermal Management:​ Ensure adequate ventilation, especially in high ambient temperatures. The unit includes temperature monitoring.

7. Grounding:​ Follow manufacturer's grounding instructions for both power and Ethernet shield grounding.

8. Software Updates:​ Regular firmware updates may be available. Establish procedures for secure firmware management.

9. Data Integration:​ The Modbus TCP interface allows integration with most control systems. Map registers appropriately for your application.

10. Documentation:​ Use the web interface's logging and reporting features for maintenance records and audit trails.

Note: This data sheet provides general specifications for the MTL 4549 advanced fieldbus power supply with Ethernet diagnostics. For complete installation guidelines, network configuration, web interface manual, Modbus register map, and safety instructions, consult the official MTL 4500 Series Technical Manual​ and 4549 Configuration Guide. Always verify that the product configuration matches your application requirements and implement appropriate cybersecurity measures for networked devices.
