Product Overview

The Eaton DIL A-22C is a Motor Protection Circuit Breaker (MPCB) from the DIL M Series, designed to provide complete protection for three-phase motors. It combines the functions of a circuit breaker, overload relay, and short-circuit protector in a single device. The "A-22C" indicates a 22A rated current for motor protection applications, offering adjustable overload protection and magnetic short-circuit tripping.

Technical Specifications

Key Features

• Integrated Motor Protection:​ Combines overload, short-circuit, and phase-loss protection

• Adjustable Settings:​ Magnetic and thermal trip settings for precise motor protection

• High Breaking Capacity:​ 100kA at 400V AC for reliable short-circuit interruption

• DIN Rail Mounting:​ Easy installation on standard 35mm DIN rail

• Manual Operation:​ Rotary handle for ON/OFF switching and tripped position indication

• Auxiliary Contacts:​ Can be equipped with add-on auxiliary contact blocks

• Trip-Free Mechanism:​ Ensures contacts cannot be held closed during fault conditions

• Visual Status:​ Clear ON/OFF/tripped indication

• Motor Isolation:​ Can be used as a manual motor isolator switch

• Compact Design:​ Saves panel space compared to separate components

Applications

• Motor protection for pumps, fans, compressors, and conveyors

• Three-phase motor starter circuits

• Machine tool motor protection

• HVAC equipment motor control

• Industrial motor control centers (MCCs)

• Any application requiring coordinated motor protection

Important Notes

1. Select based on motor full load current (FLC) and starting characteristics

2. Magnetic trip setting should be adjusted based on motor starting current

3. Thermal trip setting should be set to motor FLC (adjusted for ambient temperature if needed)

4. Consider adding auxiliary contacts for remote status indication

5. Installation should comply with local electrical codes and standards
