6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC

6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC
6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC 6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC 6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC

Large Image :  6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC Get Best Price

Product Details:
Place of Origin: DE
Certification: ATEX
Model Number: 6ES7 214-1AG40-0XB0
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

S7-1200 CPU 1214C PLC

,

PROFINET PLC with 24V DC

,

14 DI 10 DO 2 AI PLC

6ES7214-1AG40-0XB0 | S7-1200 CPU 1214C DC/DC/DC — 14 DI / 10 DO / 2 AI, PROFINET, 24V DC
6ES7214-1AG40-0XB0 SIMATIC S7-1200 CPU 1214C — 14×24V DC inputs, 10×24V DC transistor outputs, 2×AI 0–10V, PROFINET port, 100 KB work memory. Expandable with SM/SB/CM modules.

Product Overview

6ES7214-1AG40-0XB0​ is a SIMATIC S7-1200 CPU 1214C DC/DC/DC​ — the mid-range S7-1200 CPU with integrated 14 digital inputs (24 V DC sink/source), 10 digital outputs (24 V DC sourcing transistor — 0.5 A per point), and 2 analog inputs (0–10 V, 12-bit + sign). It features a built-in PROFINET RJ-45 port​ (10/100 Mbps) for programming, HMI connection, and as an IO-Controller for distributed I/O (up to 16 devices). The CPU is powered by 24 V DC​ and supports up to 8 signal modules (SM), 3 communication modules (CM/CP), and 1 signal board (SB)​ onboard. Program memory is 100 KB, data memory 4 MB​ (retentive). Programming is via TIA Portal (STEP 7 V13+ / V17/V18). Suitable for machine control, packaging, material handling, and building automation.

Technical Specifications (I/O & Memory)

Parameter
Specification
Order Number​
6ES7214-1AG40-0XB0​ (S7-1200 CPU 1214C DC/DC/DC, 4th Gen / FW ≥ V4.0)
Series​
SIMATIC S7-1200 — CPU 1214C
Power Supply​
24 V DC​ (20.4–28.8 V DC), typ. 400 mA @ 24 V DC (no load)
Digital Inputs (DI)​
14 × 24 V DC (IEC 61131-2 Type 1, sink/source)​ — 6 × HSC (max. 100 kHz), 2 × HSC (30 kHz)
Digital Outputs (DO)​
10 × 24 V DC Transistor (Sourcing), 0.5 A per point, short-circuit protected​ — grouped 6 + 4
Analog Inputs (Onboard)​
2 × 0–10 V DC (unipolar 12-bit + sign / 11-bit effective)​ — shared with 0–20 mA via external shunt
High-Speed Counters (HSC)​
Up to 6 × (max. 100 kHz on I0.0–I0.5), 2 × 30 kHz (I0.6–I0.7)
Pulse Train Outputs (PTO/PWM)​
4 × (max. 100 kHz on Q0.0–Q0.3) — for stepper/servo control
Work / Program Memory​
100 KB​ (user program + code blocks)
Load Memory (Retentive Data)​
4 MB​ (internal retentive area; micro SD card for program backup/recipe)
Expandability​
Max. 8 SM (Signal Modules)​ + 1 SB (Signal Board on CPU)​ + 3 CM/CP (Comm. Modules)​

Technical Specifications (Communication & Mechanical)

Parameter
Specification
PROFINET Interface​
1 × RJ-45 — 10/100 Mbps, auto MDI/MDIX
• IO-Controller (max. 16 I/O devices)
• PG/OP communication, Web server, SNMP
Additional Ports​
Optional via CM: RS-232/485 (CM 1241), PROFIBUS-DP Master/Slave (CM 1243-5), GPRS (CP 1242-7), etc.
Real-Time Clock (RTC)​
Buffered by supercap (typ. 20 days at 25 °C) + optional battery board (SB 1232 BA)
Operating Temperature​
-20 … +60 °C​ (horizontal); -20 … +50 °C (vertical with SM attached)
Mounting​
35 mm DIN Rail (EN 50022) or panel mount (M4 screws)
Dimensions (W × H × D)​
110 × 100 × 75 mm
Weight (Approx.)​
0.415 kg
Degree of Protection​
IP20 (installed in enclosure)
Certifications​
CE, UL 508, cULus, FM Cl. I Div. 2 Gr. A/B/C/D, KC, RCM, EAC
SD Card Slot​
Yes — for program copy, firmware update, data logging (SIMATIC MC 24MB–2GB)

Key Features

  • PROFINET Built-In:​ Native Ethernet for programming, HMI (Basic/Comfort panels), and distributed I/O — no add-on card required.
  • Transistor Outputs with PTO/PWM:​ Four 100 kHz PTO channels for stepper/servo motion control directly from the CPU.
  • Flexible Expansion:​ Add SM 1221/1222/1223 (digital), SM 1231/1232/1234 (analog), SB for extra I/O or analog in/out on-CPU, CM for serial/fieldbus.
  • Web Server & SNMP:​ Built-in web pages for diagnostics; SNMP for network monitoring — valuable in integrated plant IT.
  • TIA Portal Native:​ Fully integrated in Totally Integrated Automation Portal — drag-and-drop configuration, online diagnostics, trace functions.

Typical Applications

  • Packaging / Converting Machinery:​ Multi-axis servo/stepper via PTO + PROFINET HMI + remote I/O for ancillary stations.
  • Conveyor & Material Handling:​ Distributed control with ET 200SP/AL I/O via PROFINET; local DI/DO for start/stop/jog/estop.
  • Process Skid Auxiliaries:​ Small batch blending, CIP skid control — analog in for temp/pressure, digital I/O for pump & valve, PROFINET to DCS/MES.
  • Building Automation / HVAC:​ AHU/Chiller local control with BACnet or Modbus TCP via CP, or OPC UA (FW V4.2+ with license).
Variant note: DC/DC/DC​ = 24V DC powered, 24V DC inputs, 24V DC transistor outputs (this item). Other 1214C variants: 6ES7214-1BG40-0XB0​ = AC/DC/RLY (120/230V AC power, relay outputs), 6ES7214-1HG40-0XB0​ = DC/DC/RLY (24V DC power, relay outputs). For S7-200 legacy migration, the 1214C DC/DC/DC is the closest functional upgrade to a CPU 224XP DC/DC/DC.
