6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC

6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC
6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC 6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC 6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC 6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC

Large Image :  6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC Get Best Price

Product Details:
Certification: ATEX
Model Number: 6AV2 123-2JB03-0AX0
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

7 inch TFT touch panel PROFINET

,

KTP700 Basic PN 24V DC

,

SIEMENS PLC touch screen 6 keys

6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC
6AV2123-2JB03-0AX0 SIMATIC HMI KTP700 Basic PN — 7" widescreen TFT (65536 colors), 800×480, 1× PROFINET, touch + 6 function keys, configured with WinCC Basic V13+ (TIA Portal). 24 V DC.

Product Overview

6AV2123-2JB03-0AX0​ (commonly written 6AV2 123-2JB03-0AX0) is a SIMATIC HMI KTP700 Basic PN​ — the widescreen 7-inch Basic Panel combining a resistive touchscreen​ with 6 freely programmable function keys (with LEDs). It features a 7" TFT display (65536 colors, 800 × 480 pixels — 16:9 WVGA), a single PROFINET (Ethernet 10/100 Mbps) interface​ for connection to SIMATIC S7-1200 / S7-1500 / S7-300/400 controllers, and is configured exclusively via WinCC Basic (included in TIA Portal V13 SP1 or later). Powered by 24 V DC, the panel has a USB 2.0 host port​ for mouse, keyboard, printer, or firmware update via USB stick. The KTP700 Basic is the direct successor to the older TP170/OP177 micro panels in the S7-1200 ecosystem.

Technical Specifications (Display & Interface)

Parameter
Specification
Order Number​
6AV2123-2JB03-0AX0​ (KTP700 Basic PN)
Series​
SIMATIC HMI — Basic Panels 2nd Generation (KTPxxx Basic PN)
Display Type / Size​
7" TFT LCD (Widescreen 16:9), anti-glare​
Resolution​
800 × 480 pixels (WVGA)​
Colors​
65,536 (16-bit)
Touch Operation​
Yes — Analog Resistive (finger / stylus)
Function Keys​
6 × Freely Programmable Membrane Keys + 6 × LEDs (green)​
Interfaces (Onboard)​
1 × PROFINET RJ-45 (10/100 Mbps, auto MDI/MDIX)
1 × USB 2.0 Host (Type A)​ — front accessible
Configurable With​
WinCC Basic V13 SP1 / V14 / V15 / V16 / V17 / V18 (TIA Portal)​ — included in Basic/Professional licenses

Technical Specifications (Electrical & Mechanical)

Parameter
Specification
Supply Voltage​
24 V DC​ (Allowable 19.2–28.8 V DC, reverse-polarity protected)
Current Consumption (typ.)​
≈ 0.35 A @ 24 V DC (backlight on, typical)
Backlight Life (typ.)​
20,000 h (dimming configurable; turn-off timer available)
Real-Time Clock (RTC)​
Buffered by supercap (typ. 6 weeks hold) — no battery required
Project Memory (Internal)​
10 MB (user screens, tags, recipes, alarms)
Alarm Buffer (Internal)​
256 entries (cyclic / linear selectable)
Degree of Protection​
Front: IP65 (when properly gasket-mounted)
Rear: IP20​
Mounting Cutout​
197.0 × 141.0 mm (vertical × horizontal)
Dimensions (W × H × D)​
214 × 158 × 52 mm (panel + rear electronics)
Operating Temp.​
0 … +50 °C​
Weight (Approx.)​
0.95 kg
Certifications​
CE, cULus, FM Cl I Div 2 Grps A–D, KC, EAC, RCM
Ingress Protection (Front)​
IP65 (sealed faceplate — requires proper panel cutout gasket)

Key Features

  • PROFINET Native Connectivity:​ Direct connection to S7-1200 / S7-1500 / S7-300 via Ethernet — no MPI/DP adapter needed; supports S7-1200 symbolic addressing.
  • Touch + Physical Keys:​ Combines modern touch UI with tactile function keys preferred by operators for acknowledge, mode select, or emergency override.
  • TIA Portal Integration:​ Drag-and-drop screen creation, online simulation, and direct tag import from PLC project — reduces engineering time vs. WinCC flexible legacy panels.
  • USB for Data & Service:​ Load recipes, log alarms to USB stick, or perform firmware updates without a PG.
  • Widescreen 16:9 Format:​ More screen real estate for multi-variable displays vs. old 4:3 Basic Panels (TP170micro / OP73micro).

Typical Applications

  • S7-1200 / S7-1500 Machine HMI:​ Operator interface for packaging, labeling, converting, and special machinery — local start/stop, setpoint entry, alarm ack.
  • Small Process Skids:​ Local visualization of pump status, tank level, and valve position with 6 customizable hard keys for mode change or manual override.
  • Retrofit of Legacy Panels:​ Drop-in upgrade for TP170B Basic / OP77B (requires new cutout check — KTP700 Basic is 7" widescreen vs. 5.7" 4:3 of older OP73micro/TP170micro — cutout differs).
  • OEM Equipment Front Panel:​ Cost-effective color HMI with PROFINET for new machine builds in the  ecosystem.

6AV2123-2JB03-0AX0 | KTP700 Basic PN — 7" TFT Touch + 6 Keys, PROFINET, 24V DC 0
