SMC SY9520-5DZD | 5-Port Solenoid Valve, SY9000 Series
|
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Construction: | Relieving Type | Fluid Compatibility: | Compressed Air (non-lubricated) |
|---|---|---|---|
| Bore Size: | 20 Mm | Operatingpressurerange: | 0.1 To 1.0 MPa |
| Pickup System: | Fishman | Body Size: | 1/8 Standard |
| Pressure Gauge Port: | G 1/8 (optional) | Port Connection: | G 1/4 (inlet/outlet) |
| Fluid: | Air | ||
| Highlight: | 5-port solenoid valve SY9000 series,SMC SY9520-5DZD solenoid valve,industrial solenoid valve with warranty |
||
SMC SY9520-5DZD | 5-Port Solenoid Valve, SY9000 Series
Product Overview
The SMC SY9520-5DZD is a 5-port pilot solenoid valve designed for industrial pneumatic applications. This compact valve features G 1/4 threaded connections and operates on 220/230 V AC power, providing reliable control of compressed air systems. Part of the SY9000 series, this valve offers high flow performance with low power consumption in a space-efficient design, making it ideal for automation, manufacturing, and process control applications.
Key Features
-
5-Port Configuration - Versatile port arrangement for complex pneumatic circuits
-
Pilot Operation - Internal pilot design for reliable performance
-
High Flow Capacity - Designed for efficient air flow with minimal pressure drop
-
Compact Design - Space-saving construction for easy integration
-
Threaded Connections - G 1/4 ports with Rc internal thread interface
-
Low Power Consumption - 0.1 W with power saving circuit for energy efficiency
-
Industrial Grade - Robust construction for demanding industrial environments
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model Number |
SY9520-5DZD |
|
Manufacturer |
SMC Corporation |
|
Product Type |
5-Port Pilot Solenoid Valve |
|
Series |
SY9000 Series |
|
Power Supply |
220/230 V AC |
|
Port Size |
G 1/4 |
|
Thread Type |
Rc Internal Thread |
|
Operating Pressure Range |
0.2-0.7 MPa |
|
Effective Area (Cv) |
0.82 |
|
Power Consumption |
0.1 W (with power saving circuit) |
|
Ambient Temperature |
Standard industrial range |
|
Fluid |
Air |
|
Country of Origin |
Japan |
Performance Characteristics
-
Flow Performance - High flow capacity with low power consumption
-
Response Time - Fast response for precise control
-
Repeatability - Consistent performance over multiple cycles
-
Long-term Stability - Reliable operation over extended periods
-
Pressure Range - Wide operating pressure from 0.2 to 0.7 MPa
Electrical Specifications
-
Rated Voltage - 220/230 V AC
-
Power Consumption - 0.1 W with power saving circuit
-
Insulation Class - Standard industrial rating
-
Protection Rating - Suitable for industrial environments
-
Coil Material - Copper winding
Mechanical Specifications
-
Housing Material - Industrial-grade materials
-
Process Connection - G 1/4 threaded ports
-
Mounting Options - Body ported or base mounted styles
-
Weight - Compact and lightweight design
-
Tightening Torque - Standard industrial specifications
Applications
-
Industrial Automation - Pneumatic control in automation equipment and assembly lines
-
Manufacturing Processes - Flow control in production equipment
-
Machine Tools - Pneumatic actuation in machining equipment
-
Packaging Machinery - Air control in packaging systems
-
Assembly Equipment - Pneumatic control in assembly lines
-
Process Control - Flow regulation in manufacturing processes
-
Semiconductor Equipment - Precision control in cleanroom environments
Environmental Compliance
-
Operating Temperature - Standard industrial range
-
Storage Temperature - Standard industrial range
-
Certification - RoHS compliant
-
Origin - Japan
Installation Requirements
-
Mounting - Direct threaded installation or base mounting
-
Process Connection - G 1/4 ports with appropriate sealing
-
Electrical Connection - 220/230 V AC power supply
-
Environment - Standard industrial environments
-
Protection - Standard industrial protection requirements
Maintenance
-
Regular Inspection - Check for physical damage and proper operation
-
Cleaning - Keep connections clean and free from debris
-
Electrical Testing - Verify power supply and coil operation
-
Seal Inspection - Check seals periodically for wear and replace as needed
-
Performance Verification - Monitor flow and response characteristics
