ABB 3BSE013230R1 CI867 Ethernet Module | PROFINET IO Controller

ABB 3BSE013230R1 CI867 PROFINET module. For 800xA, 4 ports, RT/IRT, connects S800 I/O. Industrial Ethernet integration.

Product: ABB 3BSE013230R1 CI867 PROFINET Communication Interface

The ABB 3BSE013230R1 (CI867) is a PROFINET IO Controller module for the S800 I/O system within ABB's Extended Automation 800xA. It enables direct, high-speed integration of S800 I/O and other PROFINET IO Devices into the 800xA control network.

Key Features

• PROFINET IO Controller:​ Manages real-time data exchange with connected PROFINET IO Devices.

• High-Performance Networking:​ Supports PROFINET RT (Real-Time) and IRT (Isochronous Real-Time).

• Four-Port Switch:​ Four 100 Mbps Ethernet ports for flexible network topologies (line, star, ring).

• S800 I/O Integration:​ Directly connects S800 I/O racks as local PROFINET devices.

Technical Specifications

Function & Application

The CI867 acts as a bridge between the 800xA controller and PROFINET field devices. It allows the 800xA system to centrally manage and exchange process data with a wide range of third-party PROFINET-compatible sensors, drives, and remote I/O, facilitating open and integrated plant architectures.

Typical Applications

• Integrating third-party PROFINET devices (e.g., drives, remote I/O, instruments) into an 800xA control system.

• Creating high-speed, deterministic control networks for machine automation within a process plant.

• Connecting S800 I/O racks over a standard industrial Ethernet backbone.

Critical System Note

This is a system communication module​ and requires an 800xA environment. Key dependencies include:

• An S800 mounting unit​ (e.g., TU847) for installation.

• S800 I/O modules​ (if used as a local bus master).

• Configuration and engineering within the 800xA System Engineering Workplace​ using the PROFINET IO Configuration tool.

• Proper network design and device configuration for RT/IRT communication.

Note: Specifications are for product identification and comparison. This module enables open network integration. For detailed network planning, GSDML file management, and configuration guidelines, consult the official ABB CI867 PROFINET IO User Manual (3BSE050091R0101).
