Product: ABB 3BSE013231R1 CI867A PROFINET Communication Interface

The ABB 3BSE013231R1 (CI867A) is a PROFINET IO Controller communication module for the S800 I/O system, designed for ABB's Extended Automation 800xA. It facilitates high-performance, deterministic integration of S800 I/O and third-party PROFINET IO Devices into a unified control architecture.

Key Features

• PROFINET IO Controller:​ Central management of connected PROFINET field devices.

• High-Speed Real-Time Communication:​ Supports PROFINET RT and IRT for time-critical applications.

• Integrated 4-Port Switch:​ Enables flexible network topologies (line, star, ring) without external switches.

• Seamless 800xA Integration:​ Directly connects S800 I/O as local devices on the PROFINET network.

Technical Specifications

Function & Application

The CI867A module enables the 800xA controller to act as a PROFINET master, exchanging real-time process data with a wide array of intelligent field devices. This is essential for creating open, vendor-agnostic networks that combine process control with high-speed machine control.

Typical Applications

• Integrating high-speed machine automation (e.g., packaging lines, robots) with a process DCS.

• Connecting distributed remote I/O panels over a single Ethernet cable.

• Implementing synchronized motion control applications using IRT.

• Building converged plant-wide networks using standard PROFINET.

Critical System & Configuration Note

This is an advanced system component​ integral to the 800xA platform. Successful deployment requires:

• An S800 mounting unit​ (e.g., TU847, TU848) for housing and power.

• Proper configuration within the 800xA Engineering Workplace​ using specific PROFINET IO configuration tools.

• Access to and management of GSDML files​ for third-party PROFINET devices.

• Careful network planning for real-time (RT/IRT) traffic to ensure performance.

Note: Specifications are for product identification and comparison. This module supports advanced industrial networking. For network design, IRT configuration, and detailed integration procedures, consult the official ABB CI867A PROFINET IO User Manual (3BSE050091R0101).
