ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC

ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC
ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC

Large Image :  ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC Get Best Price

Product Details:
Place of Origin: CN
Brand Name: ABB
Certification: ATEX
Model Number: 1SFL587074R8411
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

ABB top-mounted auxiliary contact

,

AF09Z-30-10-84 1NO+1NC contact

,

ABB positioner auxiliary switch

ABB 1SFL587074R8411 | AF09Z-30-10-84 Top-Mounted Auxiliary Contact, 1NO+1NC
ABB 1SFL587074R8411 top-mounted auxiliary contact block. 1NO+1NC (CA5), screw terminals, for AF09–AF38 contactors, -40 to +70°C, IP20 finger-safe.

Product Overview

The ABB 1SFL587074R8411​ is the ordering reference for the AF..-30..-84 front- or top-mounted auxiliary contact block​ (commercially: CA5-10/84​ or AF09Z-30-10-84​ depending on catalog year). It adds 1 Normally Open (NO) + 1 Normally Closed (NC) contact​ to ABB AF series contactors from AF09 up to AF38. It features screw clamp terminals, IP20 finger-safe design, and a mechanical life of 10 million operations, making it the standard add-on for control circuit feedback and interlocking.

Technical Specifications (Electrical & Contact)

Parameter
Specification
ABB Catalog / Old Ref​
1SFL587074R8411​ (CA5-10 / AF09Z-30-10-84 equivalent)
Function​
Auxiliary Contact Block (Front / Top Mount)
Contact Configuration​
1 NO + 1 NC (1 Changeover pair)​
Rated Insulation Voltage (Ui)​
690 V AC​
Rated Impulse Withstand (Uimp)​
6 kV​
Conventional Free-Air Thermal Current (Ith)​
10 A​ (AC-15: 6 A @ 230 V AC)
Utilisation Category​
AC-15 (Control Circuit)
Terminal Type​
Screw Clamp​ (IP20 finger-safe)

Technical Specifications (Mechanical & Environmental)

Parameter
Specification
Mounting Position​
Front / Top of Contactor​ (snap-on)
Compatible Contactors​
ABB AF09, AF12, AF16, AF26, AF30, AF38​ (AF..-30.. base units)
Mechanical Life​
10,000,000 Operations​
Operating Temperature​
-40 °C ... +70 °C​
Storage Temperature​
-55 °C ... +80 °C
Pollution Degree​
3
Standards​
IEC 60947-5-1, EN 60947-5-1, UL 508, CSA C22.2 No.14
Weight (Approx.)​
0.04 kg

Key Features

  • Snap-Fit Installation:​ Clips directly onto the front/top of the AF contactor — no tools or wiring changes to the main contactor.
  • Dual Contact (NO+NC):​ Provides both a make (NO) and break (NC) signal for interlock, pilot lamp, or PLC feedback in a single slim block.
  • Finger-Safe Terminals:​ IP20-rated screw terminals with shrouded openings prevent accidental contact during wiring.
  • Wide Temperature Range:​ Rated for -40°C to +70°C ambient — suitable for both heated indoor panels and unconditioned enclosures.

Applications

  • Control Circuit Feedback:​ Providing NO/NC dry contacts to PLC DI cards for contactor "picked up" status.
  • Electrical Interlocking:​ Cross-wired NC contacts between forward/reverse contactors to prevent simultaneous closure.
  • Pilot Device Switching:​ Directly driving status lamps, alarms, or small control relays from the auxiliary contact.
Note: For AF40–AF125 contactors, a different auxiliary block family (CA7 / CA11 series) is required. The part number 1SFL587074R8411​ corresponds to the CA5-10 auxiliary for the AF09–AF38 range — often quoted as AF09Z-30-10-84​ in newer ABB documentation.
