1056-01-22-38-AN | 1056 Dual-Channel Analyzer, pH/ORP + Conductivity, 4–20mA, NEMA 4X

Large Image : 1056-01-22-38-AN | 1056 Dual-Channel Analyzer, pH/ORP + Conductivity, 4–20mA, NEMA 4X Get Best Price

Product Details:

Place of Origin:	SG
Certification:	ATEX
Model Number:	1056-01-22-38-AN
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

Ambient Temperature:

Electrical Rating:

Certifications:

Highlight:

Rosemount pH sensor dual-channel analyzer

pH ORP conductivity analyzer 4-20mA

NEMA 4X dual-channel water analyzer

1056-01-22-38-AN | 1056 Dual-Channel Analyzer, pH/ORP + Conductivity, 4–20mA, NEMA 4X

1056-01-22-38-AN dual-input smart transmitter — Ch1: pH/ORP/ISE/DO, Ch2: Conductivity/Resistivity/Temp. 2×4–20mA, relays, backlit LCD, 100–240V AC, NEMA 4X / IP66.

Product Overview

1056-01-22-38-AN is a dual-input microprocessor-based smart analyzer/transmitter from 1056 series, designed for continuous online monitoring in municipal and industrial applications. It is factory-configured with Channel 1 = pH / ORP / ISE / Dissolved Oxygen (universal analog input) and Channel 2 = Conductivity / Resistivity / Temperature (2-electrode or 4-electrode probe compatible). The unit provides two isolated 4–20 mA outputs (one per channel), four programmable SPDT relay contacts for alarm or control, and a backlit alphanumeric LCD for local configuration and reading. Power is 100–240 V AC 50/60 Hz. The NEMA 4X / IP66 wall-mount or panel-mount enclosure suits washdown and outdoor panel locations. Compatible with 3900 / 396 / 398 pH sensors, 342 / 344 / 346 conductivity cells, and 499 DO probes.

Technical Specifications (Input & Measurement)

Parameter	Specification
Model Code	1056-01-22-38-AN
Series	1056 Dual-Channel Intelligent Analyzer
Channel 1 (Primary)	pH / ORP / ISE / Dissolved Oxygen (DO) — auto-detects sensor type on connect
Channel 2 (Secondary)	Conductivity / Resistivity / Temperature — 2-electrode or 4-electrode cell, 0.055–5000 µS/cm cell constant supported
pH Range	0.00 … 14.00 pH (± 2000.0 mV for ORP)
Conductivity Range	0.001 µS/cm … 999.9 mS/cm (auto-ranging per cell constant)
Temperature Compensation	Pt100 / Pt1000 RTD — built into sensor; programable α-coefficient
Accuracy (pH)	± 0.01 pH (typical, with calibrated sensor)
Accuracy (Cond.)	± 0.5 % FS (typical, with matched cell)
Display	Backlit 2-line × 16-character alphanumeric LCD — English/selectable language

Technical Specifications (Outputs & Mechanical)

Parameter	Specification
Analog Outputs	2 × Isolated 4–20 mA DC (sourcing or sinking, software-selectable assignment — Ch1 & Ch2) — max. loop resistance 600 Ω @ 24 V
Relay Outputs	4 × SPDT (Form C) electromechanical relays — 5 A @ 250 V AC / 30 V DC resistive — programmable as Hi / Lo / Hi-Hi / Lo-Lo / Timer / Wash
Power Supply	100–240 V AC (±10 %), 50/60 Hz, typ. 15 VA
Enclosure Rating	NEMA 4X / IP66 — Polycarbonate or Fiberglass Reinforced Polyester (FRP), gasketed
Mounting	Wall-mount (std.) or Panel-mount (cutout 138 × 138 mm)
Operating Temp. (Ambient)	-20 … +60 °C (-4 … +140 °F)
Humidity	0–95 % RH non-condensing
Electrical Connection	Screw terminals — power, analog loops, relay contacts, sensor pigtails
Certifications	CE, CSA / cULus General Purpose, FM (some variants Div 2) — confirm per region
Weight (Approx.)	1.8 kg

Key Features

Dual Independent Channels: Monitor pH/ORP on one loop and Conductivity/Resistivity on another — eliminates need for two separate analyzers.
Universal Sensor Recognition (Ch1): Auto-configures for pH, ORP, ISE, or DO probe — simplifies spare stocking and commissioning.
Four Programmable Relays + 2×4–20 mA: Supports alarm, sample-wash timer, limit control, or failsafe actions — fully software-assignable.
One-Button Calibration with Prompted Menus: Step-by-step pH 2-/3-point, conductivity 1-point, DO air/zero calibration via front keypad.
NEMA 4X / IP66 Enclosure: Suitable for outdoor shelters, washdown areas, and corrosive plant atmospheres.

Typical Applications

Semiconductor / Pharma UPW: Conductivity/resistivity (Ch2) + pH/orp (Ch1) on ultrapure water loops.
Wastewater Treatment: pH control in neutralization basin (Ch1) + conductivity trend of influent/effluent (Ch2).
Cooling Tower / Boiler Feed: pH monitoring + blowdown conductivity control from a single analyzer.
Food & Beverage CIP: pH verification of caustic/acid wash + conductivity check of final rinse water.

1056 model decode: 1056 = Dual-channel analyzer | -01 = Ch1: pH/ORP/ISE/DO universal | -22 = Ch2: Conductivity/Resistivity/Temp | -38 = 100–240V AC power, 2×4–20mA, 4 relays, NEMA 4X, Eng/French display | -AN = No special agency (std.), ANSI/ISA term. strip. Sensors (e.g. 3900VP-01-10) and installation hardware ordered separately.

If you need single-channel (1055) or HART/Profibus option, see 1056-…-H or -P variants.
