SMC CDJ2B20-25Z | Air Cylinder, Double Acting, Single Rod
Product Overview
The SMC CDJ2B20-25Z is a compact, double-acting air cylinder with a built-in magnet, designed for industrial automation applications. This precision pneumatic cylinder features a 20mm bore size and 25mm stroke length, providing reliable linear motion in a space-efficient design. With its robust construction and versatile mounting options, this cylinder is ideal for automation, assembly, and manufacturing processes where precision and reliability are essential.
Key Features
-
Double-Acting Operation - Pneumatic operation in both directions for precise control
-
Built-in Magnet - D-type magnet for position sensing applications
-
Compact Design - Space-efficient construction for tight installation spaces
-
Rubber Cushioning - End-of-stroke cushioning for smooth operation and reduced impact
-
Basic Mounting - B-type mounting for easy integration into existing systems
-
Industrial Grade - Robust construction for demanding industrial environments
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model Number |
CDJ2B20-25Z |
|
Manufacturer |
SMC Corporation |
|
Product Type |
Double-Acting Air Cylinder |
|
Bore Size |
20mm |
|
Stroke Length |
25mm |
|
Magnet Type |
D (Built-in) |
|
Mounting Type |
B (Basic) |
|
Cushion Type |
Rubber Cushion |
|
Head Cover |
Perpendicular to Axis |
|
Pivot Bracket |
None |
|
Rod End Bracket |
None |
|
Auto Switch |
No Switch |
|
Weight |
0.100 kg |
|
HS Code |
84123100 |
Performance Characteristics
-
Bore Sizes Available: 6mm, 10mm, 16mm, 20mm
-
Stroke Range: Up to 400mm
-
Cushion Options: Rubber cushion or air cushion
-
Mounting Options: Multiple head covers and mounting brackets available
-
Auto Switch Compatibility: 2-colour indication solid state auto switches can be mounted
-
Fine Adjustment: Easy adjustment of auto switch position by loosening one screw
Mechanical Specifications
-
Housing Material: Industrial-grade materials
-
Process Connection: Standard pneumatic ports
-
Electrical Connection: Not applicable (pneumatic device)
-
Tightening Torque: Standard industrial specifications
-
Shock Resistance: Suitable for industrial environments
-
Vibration Resistance: Designed for stable operation in vibrating applications
Applications
-
Industrial Automation - Integration into automation equipment and assembly lines
-
Manufacturing Processes - Precision linear motion in production equipment
-
Assembly Equipment - Automated assembly and positioning systems
-
Packaging Machinery - Motion control in packaging and material handling
-
Machine Tools - Pneumatic actuation in machining equipment
-
Semiconductor Equipment - Precision positioning in cleanroom environments
-
Robotics - Integration into robotic systems and end effectors
Environmental Compliance
-
Operating Temperature: Standard industrial range
-
Storage Temperature: Standard industrial range
-
Certification: RoHS compliant
-
Origin: Japan
Installation Requirements
-
Mounting: Basic mounting (B-type) with standard mounting holes
-
Process Connection: Standard pneumatic connections
-
Environment: Standard industrial environments
-
Protection: Standard industrial protection requirements
Maintenance
-
Regular Inspection: Check for physical damage and proper operation
-
Lubrication: Follow manufacturer's lubrication recommendations
-
Cleaning: Keep connections clean and free from debris
-
Seal Inspection: Check seals periodically for wear and replace as needed
