SMC SY7220-4DZD | 5-Port Solenoid Valve, SY Series
|
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Color: | Blue | Portsize: | Varies (1/8", 1/4", 3/8", 1/2") |
|---|---|---|---|
| Maximum Input Pressure: | 1.0 MPa | Rated Voltage: | 24 VDC |
| Productname: | SMC Instruments | Operatingtemperaturerange: | -10°C To 60°C |
| Cylinder Side Size: | R 1/8 | Duty Cycle: | 100% Continuous |
| Flow Rate: | ~1,000 L/min (ANR) | ||
| Highlight: | 5-port solenoid valve SY series,SMC SY7220-4DZD valve,industrial solenoid valve with warranty |
||
SMC SY7220-4DZD | 5-Port Solenoid Valve, SY Series
Product Overview
The SMC SY7220-4DZD is a 5-port pilot solenoid valve designed for industrial pneumatic applications. This compact valve features G 1/4 threaded connections and operates on 220/230 V AC power, providing reliable control of compressed air systems. Part of the SY7000 series, this valve offers high flow performance with low power consumption in a space-efficient design, making it ideal for automation, manufacturing, and process control applications.
Key Features
-
5-Port Configuration - Versatile port arrangement for complex pneumatic circuits
-
Pilot Operation - Internal pilot design for reliable performance
-
High Flow Capacity - Designed for efficient air flow with minimal pressure drop
-
Compact Design - Space-saving construction for easy integration
-
Threaded Connections - G 1/4 ports with Rc internal thread interface
-
Industrial Grade - Robust construction for demanding industrial environments
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model Number |
SY7220-4DZD |
|
Manufacturer |
SMC Corporation |
|
Product Type |
5-Port Pilot Solenoid Valve |
|
Series |
SY7000 Series |
|
Power Supply |
220/230 V AC |
|
Port Size |
G 1/4 |
|
Thread Type |
Rc Internal Thread |
|
Operating Pressure Range |
0.1-0.7 MPa |
|
Effective Area (Cv) |
10.6 mm² (0.59) |
|
Response Time |
32ms or less (at 0.5MPa) |
|
Ambient Temperature |
-10°C to 50°C |
|
Fluid |
Air |
|
Country of Origin |
Japan |
Performance Characteristics
-
Flow Performance - High flow capacity with low power consumption
-
Response Time - Fast response (32ms or less) for precise control
-
Repeatability - Consistent performance over multiple cycles
-
Long-term Stability - Reliable operation over extended periods
-
Pressure Range - Wide operating pressure from 0.1 to 0.7 MPa
Electrical Specifications
-
Rated Voltage - 220/230 V AC
-
Power Consumption - Low power design for energy efficiency
-
Insulation Class - Class H
-
Protection Rating - IP65 (dust tight and water jet resistant)
-
Coil Material - Copper winding
Mechanical Specifications
-
Housing Material - Industrial-grade materials
-
Process Connection - G 1/4 threaded ports
-
Mounting Options - Body ported or base mounted styles
-
Weight - Compact and lightweight design
-
Tightening Torque - Standard industrial specifications
Applications
-
Industrial Automation - Pneumatic control in automation equipment and assembly lines
-
Manufacturing Processes - Flow control in production equipment
-
Machine Tools - Pneumatic actuation in machining equipment
-
Packaging Machinery - Air control in packaging systems
-
Assembly Equipment - Pneumatic control in assembly lines
-
Process Control - Flow regulation in manufacturing processes
-
Semiconductor Equipment - Precision control in cleanroom environments
Environmental Compliance
-
Operating Temperature - -10°C to 50°C
-
Storage Temperature - Standard industrial range
-
Certification - RoHS compliant
-
Origin - Japan
Installation Requirements
-
Mounting - Direct threaded installation or base mounting
-
Process Connection - G 1/4 ports with appropriate sealing
-
Electrical Connection - 220/230 V AC power supply
-
Environment - Standard industrial environments (-10°C to 50°C)
-
Protection - IP65 protection rating
Maintenance
-
Regular Inspection - Check for physical damage and proper operation
-
Cleaning - Keep connections clean and free from debris
-
Electrical Testing - Verify power supply and coil operation
-
Seal Inspection - Check seals periodically for wear and replace as needed
-
Performance Verification - Monitor flow and response characteristics
