Product: ABB CP1-10R-11 Indicator Light Unit

The ABB CP1-10R-11 is a single-unit, 22.5mm diameter indicator light for use with the CP1 series modular pushbutton system. It provides clear visual status indication for industrial control panels and machinery.

Key Features

• Modular Design:​ Compatible with all ABB CP1 series contact blocks and operators for flexible panel assembly.

• 22.5mm Mounting:​ Standard round hole mounting for easy installation.

• Bright LED Light Source:​ Long life, low power consumption, and high visibility.

• Screw Terminal Connection:​ Reliable and secure wiring.

Technical Specifications

Function & Assembly

This is an illumination unit. It provides a visual signal (steady red light) when powered. To build a complete indicating device, it is typically assembled in this order from the panel front to back:

1. Mounting Nut:​ Secures the unit to the panel.

2. This Unit (CP1-10R-11):​ Contains the LED and lens.

3. Optional Contact Block(s):​ Can be stacked behind it to add auxiliary contacts (e.g., CP1-21) if a confirming electrical signal is needed.

4. Blanking Element or End Plate:​ Covers the back of the assembly.

Typical Applications

Used as a status indicator on control panels for:

• Power On/Off indication

• Machine running/standby/fault status

• Process condition alerts

• Pilot lights for motors or heaters

Important Note

The suffix "-11"​ indicates the specific variant with screw terminals​ and a universal voltage LED. This unit by itself is only a light. It does not contain any switch contacts. To create a lighted pushbutton, this unit must be combined with a CP1 pushbutton operator (e.g., CP1-10-GN for a green button).

Note: Specifications are for product identification and comparison. For full assembly combinations, dimensional drawings, and compatibility, consult the official ABB CP1 Push Buttons Catalog (1SBC150015R0201).
