ABB AX12-30-10-80 | 3-Pole Contactor, 220-230V AC Coil, 12A AC-3, 1NO Auxiliary
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
ABB AX12-30-10-80 Contactor Product Overview
ABB AX12-30-10-80 is an AX series block contactor designed for industrial motor control and power circuit switching. This model features a 3-pole main contact arrangement, 1 built-in normally open auxiliary contact and an AC control coil rated at 220-230V 50Hz / 230-240V 60Hz.
The AX12-30-10-80 contactor is suitable for controlling 3-phase motors and power circuits up to 690V AC, with a compact body, screw terminals and IP20 terminal protection for installation in low-voltage control panels.
Technical Specifications - General Information
| Brand | ABB |
| Model | AX12-30-10-80 |
| Product ID | 1SBL911074R8010 |
| EAN | 3471522393807 |
| Main Contacts | 3 normally open main contacts |
| Auxiliary Contact | 1 normally open built-in auxiliary contact |
| Terminal Type | Screw terminals |
Technical Specifications - Electrical Ratings
| Rated Control Circuit Voltage | 220-230V AC 50Hz / 230-240V AC 60Hz |
| Rated Operational Voltage | Up to 690V AC |
| Rated Insulation Voltage | 690V |
| Rated Impulse Withstand Voltage | 6 kV |
| AC-3 Rated Operational Current | 12A at 220-240V, 380-400V and 415V; 9A at 440-500V; 7A at 690V |
| AC-3 Rated Operational Power | 3 kW at 220-240V; 5.5 kW at 380-400V, 415V, 500V and 690V; 4 kW at 440V |
| Conventional Thermal Current | 26A for main circuit; 16A for auxiliary circuit |
| Degree of Protection | IP20 terminals |
Dimensions and Installation Data
| Width | 44 mm |
| Depth | 74 mm |
| Height | 74 mm |
| Net Weight | 0.326 kg |
| Operating Ambient Temperature | -40 to 70 deg C without thermal overload relay |
| Storage Temperature | -60 to 80 deg C |
| Maximum Operating Altitude | 3000 m |
Key Features
- Compact ABB AX series block contactor for low-voltage motor control panels.
- 3-pole main contact design with 1NO built-in auxiliary contact.
- AC coil for 220-230V 50Hz and 230-240V 60Hz control circuits.
- Rated for AC-3 motor control duty up to 12A at common industrial voltages.
- IP20 screw terminals for practical panel wiring and maintenance.
- Certification support includes CB, CCC, CE, CQC, REACH, RoHS and UL.
Typical Applications
- Industrial motor starters and control cabinets
- Low-voltage power distribution and switching circuits
- Automation panels for pumps, fans, conveyors and machine tools
- Replacement and maintenance for ABB AX series contactor installations
