ABB 1SFA619403R5231 Shunt Trip Release | 230V AC/DC Specs

Large Image : ABB 1SFA619403R5231 Shunt Trip Release | 230V AC/DC Specs Get Best Price

Product Details:

Place of Origin:	CN
Brand Name:	ABB
Certification:	ATEX
Model Number:	1SFA619403R5231
Document:	ABB-1SFA619403R5231.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

ABB shunt trip release 230V AC/DC

ABB positioner shunt trip release

ABB 1SFA619403R5231 trip release

ABB 1SFA619403R5231 Shunt Trip Release | 230V AC/DC Specs

ABB 1SFA619403R5231 shunt trip release. Key specs: 230V AC/DC, for SACE Emax 2 air circuit breakers. Remote circuit opening.

Product: ABB 1SFA619403R5231 Shunt Trip Release

The ABB 1SFA619403R5231 is a shunt trip release accessory for SACE Emax 2 series low-voltage air circuit breakers (ACBs). It is a solenoid-actuated device that allows the circuit breaker to be tripped (opened) remotely by applying an electrical signal.

Key Features

Remote Opening: Enables electrical tripping of the breaker from a remote location.
Safety & Control: Critical for emergency stop circuits, interlocking, or remote control schemes.
Universal Compatibility: Designed for easy mounting on compatible Emax 2 ACBs.
Versatile Coil Voltage: Operates on a wide range of AC and DC control voltages.

Technical Specifications

Parameter	Specification
Order Number	1SFA619403R5231
Compatible Series	ABB SACE Emax 2 Air Circuit Breakers (E1.2, E2.2, E3.2, E4.2, E6.2)
Type	Shunt Trip Release
Rated Control Supply Voltage (Us)	230 V AC / 230 V DC
Operating Voltage Range	0.7 to 1.25 x Us (for AC: 161 - 287.5V AC; for DC: 161 - 287.5V DC)
Power Consumption at Us	Approx. 60 VA (inrush), 6 W (holding) for AC; Approx. 65 W (inrush), 6 W (holding) for DC
Maximum Closing Time	≤ 50 ms
Electrical Endurance	≥ 10,000 mechanical operations
Terminal Type	Screw Clamp
Wire Range	1.0 - 2.5 mm² (AWG 18 - 12)
Protection Rating	IP20 (as mounted on the breaker)
Mounting Position	Internally, on the left side of the breaker (viewed from front)
Function	When energized, it mechanically triggers the breaker's opening mechanism.

Function & Application

The shunt trip is an electrically operated release. When its coil is energized from an external control circuit (e.g., by an emergency stop button, fire alarm contact, or PLC output), it instantaneously activates the breaker's mechanical trip unit, causing the main contacts to open and disconnect the power.

Typical Applications

Emergency stop (E-stop) circuits for machinery.
Fire alarm system integration.
Remote trip commands from a control room.
Interlocking with other safety or process systems.

Critical Installation Note

This device must be used in conjunction with a normally-open control contact (e.g., from a pushbutton or relay). It is designed for momentary energization only. Continuous power application will damage the coil. The breaker must be manually reset (closed) after a shunt trip operation. A separate undervoltage release (UVR) is required for protection against loss of voltage.

Note: Specifications are for product identification and comparison. This is a safety-related control accessory. For correct installation, wiring diagrams, and system integration, consult the official ABB SACE Emax 2 Installation and Service Instructions (1SDH000500R0002-LOW).
