Product Overview

The Allen-Bradley 22F-D6P0N113​ is a PowerFlex® 40P Adjustable Frequency AC Drive​ designed for industrial motor control applications. This model is rated for 1.5 HP (1.1 kW)​ output, 480V three-phase AC input, and 3.4A output current. The "22F" prefix indicates the PowerFlex series and frame size, "D6P0N1" designates the specific voltage and configuration, and "13" specifies the horsepower rating. This drive provides sensorless vector control, integrated braking, and multiple communication options for precise control of standard AC induction motors in industrial automation systems.

Technical Specifications

Note: Specifications are based on Allen-Bradley PowerFlex 40P series technical documentation. The "22F-D6P0N113" model specifically indicates 1.5 HP, 480V, 3-phase configuration. Actual specifications may vary slightly depending on production batch.

Model Number Decoding (22F-D6P0N113)

• 22F:​ Series and frame designation (22 = PowerFlex series, F = Frame F)

• D6P0N1:​ Configuration code (D6 = 480V input, P0 = specific variant, N1 = standard control)

• 13:​ Horsepower rating (13 = 1.5 HP)

Note:​ The "22F" prefix indicates the PowerFlex series and the physical frame size. The "D6" portion specifies 480V AC input voltage. The "P0N1" indicates the standard configuration with certain control features. The "13" suffix is a code for the 1.5 HP rating.

Key Features

• Sensorless Vector Control:​ Provides high starting torque and precise speed control without feedback devices

• Integrated Features:​ Built-in PID controller, auto-tuning, and multiple preset speeds

• Flexible I/O:​ Multiple analog and digital inputs/outputs for versatile integration

• Communication Options:​ Built-in RS-485 port supporting Modbus RTU and Allen-Bradley DPI protocol

• Easy Programming:​ Intuitive keypad with plain English display for straightforward setup

• Motor Protection:​ Built-in overload, overcurrent, and overtemperature protection

• Multiple Stop Options:​ Coast, ramp, or DC injection stop modes

• Durable Construction:​ Industrial-grade components for reliable operation in manufacturing environments

• Application Macros:​ Pre-programmed configurations for common applications (pump, fan, conveyor, etc.)

• Harmonic Mitigation:​ Built-in DC bus choke reduces input current harmonics

Typical Applications

• Industrial Pumps:​ Variable speed control for centrifugal pumps in water treatment and process industries

• Fan Control:​ HVAC and industrial ventilation system fan speed regulation

• Conveyor Systems:​ Material handling conveyor speed and torque control

• Machine Tools:​ Spindle and feed drive control in manufacturing equipment

• Packaging Machinery:​ Speed synchronization and tension control

• Material Processing:​ Mixer, extruder, and agitator speed control

• Automation Systems:​ Integration with PLC-controlled processes

• Building Automation:​ Pump and fan control in commercial buildings

Important Technical Notes

1. Input Voltage:​ Verify input power matches 480V AC, 3-phase, 50/60 Hz. Do not apply voltage outside specified range.

2. Motor Compatibility:​ Designed for standard 3-phase AC induction motors. Verify motor specifications match drive ratings.

3. Enclosure Requirements:​ This is a chassis unit requiring installation in a suitable enclosure to achieve IP20/NEMA 1 rating.

4. Braking Requirements:​ Standard braking is limited to 50% of rated torque. For high-inertia loads or frequent stopping, an external dynamic braking resistor is required.

5. Thermal Management:​ Ensure adequate ventilation and ambient temperature does not exceed 50°C. Derate output current above 40°C ambient.

6. Wiring:​ Use proper wire sizing according to NEC/IEC standards. Follow manufacturer's guidelines for power, control, and grounding.

7. Motor Protection:​ The drive provides motor overload protection. Additional line protection (circuit breakers, fuses) is required as per electrical codes.

8. EMC Compliance:​ Install in metallic enclosure and use proper cable routing to meet EMC requirements. Additional filters may be needed for sensitive applications.

9. Programming:​ Complete motor setup and auto-tuning procedure for optimal performance. Document parameter settings for future reference.

Note: For complete installation guidelines, wiring diagrams, programming instructions, and detailed technical data, consult the official Allen-Bradley PowerFlex 40P User Manual. Always verify the exact model number configuration with the manufacturer, as notation variations may occur.
