Product Overview

The Allen-Bradley 1606-XLS240E​ is a DIN rail mounted switching power supply​ from the 1606-XLS series, designed for industrial automation and control applications. This model provides 240W output power, 24V DC nominal output voltage, and 10A output current. The "1606" designation indicates the power supply series, "XLS" specifies the product line, "240" denotes the 240W output power, and "E" indicates the specific configuration variant. This power supply features universal AC input, high efficiency, and comprehensive protection features suitable for powering PLCs, sensors, relays, and other industrial DC loads.

Technical Specifications

Note: Specifications are based on Allen-Bradley 1606-XLS series technical documentation. The "1606-XLS240E" model specifically indicates 240W, 24V DC output configuration. Actual specifications may vary slightly depending on production batch.

Model Number Decoding (1606-XLS240E)

• 1606:​ Series designation (1606 power supply series)

• XLS:​ Product line (XLS = eXtended Line Series)

• 240:​ Output power rating (240 = 240W)

• E:​ Configuration variant (E = standard 24V DC output)

Note:​ The "XLS" indicates the Extended Line Series, which features enhanced performance and reliability characteristics. The "240" denotes the 240W output power rating. The "E" suffix indicates the standard 24V DC output configuration.

Key Features

• Universal Input:​ 85-264V AC input range for worldwide operation

• High Efficiency:​ 91% typical efficiency for reduced heat generation and energy savings

• DIN Rail Mounting:​ Easy installation on standard 35mm DIN rails

• Wide Temperature Range:​ Operation from -25°C to +70°C with appropriate derating

• Comprehensive Protection:​ Overload, overvoltage, short circuit, and overtemperature protection

• Fanless Design:​ Natural convection cooling for silent operation and increased reliability

• Power OK Indicator:​ Green LED for status indication

• High Power Factor:​ 0.98 typical power factor for reduced harmonic distortion

• Adjustable Output:​ Output voltage adjustable from 22V to 28V

• Screw Terminals:​ Secure connections for power and control wiring

• Compact Design:​ Space-efficient design for control panel applications

Typical Applications

• PLC Systems:​ Power supply for Programmable Logic Controllers

• Industrial Automation:​ Power for sensors, actuators, and control circuits

• Machine Control:​ Power supply for machine tool control systems

• Process Control:​ Instrumentation and control system power

• Material Handling:​ Conveyor and sorting system power

• Packaging Machinery:​ Control power for packaging equipment

• Building Automation:​ HVAC and access control system power

• Test and Measurement:​ Laboratory and production test equipment

• Robotics:​ Power for robotic controllers and end effectors

• Safety Systems:​ Power for safety relays and emergency stop circuits

Important Technical Notes

1. Input Voltage:​ Verify input power matches 85-264V AC range. The unit also accepts 100-250V DC input.

2. Derating:​ Output current must be derated above 40°C ambient temperature. Consult derating curves in technical documentation.

3. Mounting:​ Install on 35mm DIN rail according to manufacturer's instructions. Ensure adequate clearance for ventilation.

4. Wiring:​ Use proper wire size according to current rating. Follow torque specifications for screw terminals.

5. Parallel Operation:​ This model is not designed for parallel operation. Do not connect outputs in parallel.

6. Grounding:​ Ensure proper grounding according to local electrical codes and manufacturer recommendations.

7. Load Conditions:​ Ensure load does not exceed 10A continuous current. Consider inrush current requirements for motor loads.

8. Environmental Conditions:​ Protect from excessive dust, moisture, and corrosive atmospheres. IP20 rating provides basic protection only.

9. Maintenance:​ Periodically check connections, ventilation, and operating temperature. Clean ventilation openings if necessary.

10. Replacement:​ When replacing, ensure adequate power margin for connected loads and identical electrical specifications.

Note: For complete installation guidelines, wiring diagrams, application notes, and detailed technical data, consult the official Allen-Bradley 1606-XLS Series Technical Manual. Always verify the exact model number configuration with the manufacturer, as notation variations may occur.
