The Allen-Bradley 1747-L541​ is a SLC 5/04 programmable logic controller (PLC)​ processor from the SLC 500 series, designed for industrial automation and control applications. This processor features 16K words of user memory, DH+ (Data Highway Plus) communication protocol, and operates on 24V DC power. The "1747" designation indicates the SLC 500 processor series, "L541" specifies the 5/04 series with 16K memory and DH+ communication. This controller provides enhanced network connectivity and processing power for medium automation applications requiring integration with Allen-Bradley's DH+ network architecture.

Technical Specifications

Note: Specifications are based on Allen-Bradley 1747 series technical documentation. The "1747-L541" model specifically indicates SLC 5/04 processor with 16K memory and DH+ communication. Actual specifications may vary slightly depending on production batch.

Model Number Decoding (1747-L541)

• 1747:​ Series designation (SLC 500 processor series)

• L541:​ Processor model (L5 = SLC 5/0x series, 41 = 5/04 with 16K memory and DH+)

Note:​ The "L5" prefix indicates SLC 5/0x processor family. The "41" suffix specifically identifies the SLC 5/04 processor with 16K memory and DH+ network capability. This represents a significant upgrade from the 5/03 series with faster network communication capabilities.

Key Features

• 16K User Memory:​ 16,384 16-bit words for program and data storage

• DH+ Network Connectivity:​ Built-in Data Highway Plus network communication

• Dual Communication Ports:​ DH+ network port and RS-232 programming port

• High-Speed Networking:​ DH+ speeds up to 230.4K baud

• Real-Time Control:​ Deterministic scan time for predictable control

• Battery Backup:​ Maintains memory during power loss

• Status Indicators:​ Comprehensive LED status indication including DH+ network status

• Key Switch:​ Three-position key switch for mode control

• Expandable I/O:​ Supports up to 30 local I/O (960 with expansion chassis)

• Enhanced Instruction Set:​ 72 instructions including advanced math and logical operations

• Industrial Grade:​ Designed for harsh industrial environments

• Network Integration:​ Direct connectivity to Allen-Bradley's DH+ network architecture

Memory Configuration

Communication Capabilities

Typical Applications

• Distributed Control Systems:​ Multi-processor control applications on DH+ networks

• Factory Automation:​ Integrated control systems with PLC-5 and other DH+ devices

• Material Handling:​ Complex conveyor and sorting systems

• Process Control:​ Medium-scale process automation with network requirements

• Manufacturing Cells:​ Coordinated control of multiple machines

• Water/Wastewater:​ Plant-wide control systems

• HVAC Systems:​ Large building automation with network communication

• Energy Management:​ Networked power monitoring and control systems

• Automotive Manufacturing:​ Production line control with DH+ integration

Important Technical Notes

1. System Requirements:​ Requires 1746 chassis (A4, A7, A10, A13) and 1746 power supply. Must be installed in slot 0.

2. DH+ Network:​ Requires proper network termination, addressing (0-77 octal), and cable installation. Maximum 64 nodes on DH+ network.

3. Memory Capacity:​ 16K memory suitable for medium complexity applications. Consider program size and data requirements.

4. Battery Maintenance:​ Replace lithium battery (1747-BA) every 2 years or when battery LED indicates low voltage.

5. Programming Software:​ Requires RSLogix 500 software for programming and configuration.

6. I/O Expansion:​ Local I/O limited to 30 modules. Remote I/O via 1747-ASB module expands to 960 I/O points.

7. Power Requirements:​ Ensure power supply provides adequate current for processor and I/O modules. Higher power consumption than 5/03 processors.

8. Network Configuration:​ Proper DH+ network configuration (baud rate, node address) is critical for network communication.

9. Environmental Conditions:​ Install in appropriate enclosure for protection. Operating temperature limited to 0-60°C.

Note: For complete installation guidelines, wiring diagrams, programming instructions, and detailed technical data, consult the official Allen-Bradley SLC 500 Technical Manual. Always verify the exact model number configuration with the manufacturer, as notation variations may occur.
