ABB 1SVR405613R3100 MCB | 1-Pole, 10A, C Curve, 240V AC, 6kA, DIN Rail

Large Image : ABB 1SVR405613R3100 MCB | 1-Pole, 10A, C Curve, 240V AC, 6kA, DIN Rail Get Best Price

Product Details:

Place of Origin:	PL
Brand Name:	ABB
Certification:	ATEX
Model Number:	1SVR405613R3100
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

ABB 1SVR405613R3100 MCB 10A

1-pole DIN rail MCB 6kA

C curve circuit breaker 240V

ABB 1SVR405613R3100 MCB | 1-Pole, 10A, C Curve, 240V AC, 6kA, DIN Rail

ABB 1SVR405613R3100 circuit breaker specifications. 1-pole MCB, 10A, C tripping curve, 240V AC, 6kA breaking capacity, DIN rail mount.

Product Overview

The ABB 1SVR405613R3100 is a 1-pole miniature circuit breaker (MCB) from the S200 series. It provides overcurrent and short-circuit protection for electrical circuits in residential, commercial, and light industrial installations. This model features a 10A rated current, a C characteristic tripping curve suitable for general purpose applications, and a 6kA breaking capacity at 240V AC.

Technical Specifications

Parameter	Specification
Manufacturer	ABB AG
Series	S200 Series (System pro M compact)
Type	1SVR405613R3100
Product Type	Miniature Circuit Breaker (MCB)
Number of Poles	1P
Rated Current (In)	10 A
Rated Voltage (Ue)	240 V AC
Rated Frequency	50/60 Hz
Tripping Characteristic	C (5-10 In)
Breaking Capacity (Icn)	6 kA (IEC/EN 60898)
Energy Limiting Class	3
Mounting	DIN Rail 35 mm
Electrical Life	20,000 cycles
Mechanical Life	20,000 cycles
Ambient Temperature	-25 to 60 °C (-13 to 140 °F)
Connection	Screw clamp terminals
Terminal Capacity	Up to 25 mm² (flexible)
Dimensions (W x H x D)	18 × 89 × 70 mm (1 module)
Certifications	CE, cULus, IEC/EN 60898-1, CCC, KC

Key Features

C Characteristic Curve: Suitable for protection of circuits with moderate inrush currents (lighting, sockets, general loads)
High Breaking Capacity: 6 kA ensures reliable short-circuit interruption
DIN Rail Mounting: Easy installation on standard 35 mm rail
Screw Clamp Terminals: Secure connection for solid and stranded conductors
Compact Design: 1 module width (18 mm) saves space in distribution boards
Visual Indicator: Clear ON/OFF position indication
High Quality & Reliability: Long electrical and mechanical life
Global Approvals: Complies with international standards for worldwide use

Applications

Overcurrent and short-circuit protection in final distribution circuits
Residential and commercial building wiring (lighting, power outlets)
Control panels and machinery
Light industrial applications
General circuit protection where moderate inrush currents are expected

Important Notes

The C characteristic trips at 5-10 times the rated current (In), making it suitable for circuits with standard inductive loads (motors, transformers).
This MCB is designed for AC circuits; for DC applications, a different model is required.
The breaking capacity (6 kA) is the maximum fault current the breaker can safely interrupt.
Ensure the system's prospective short-circuit current at the installation point does not exceed 6 kA.
Proper cable sizing and installation according to local electrical codes are required.
