ABB 1SVR405650R1000 MCB | 1-Pole, 16A, C Curve, 240V AC, 6kA, DIN Rail

Large Image : ABB 1SVR405650R1000 MCB | 1-Pole, 16A, C Curve, 240V AC, 6kA, DIN Rail Get Best Price

Product Details:

Place of Origin:	CN
Brand Name:	ABB
Certification:	ATEX
Model Number:	1SVR405650R1000
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

ABB 1-pole MCB 16A

DIN rail circuit breaker 6kA

C curve MCB 240V AC

ABB 1SVR405650R1000 MCB | 1-Pole, 16A, C Curve, 240V AC, 6kA, DIN Rail

ABB 1SVR405650R1000 circuit breaker specifications. 1-pole MCB, 16A, C tripping curve, 240V AC, 6kA breaking capacity, DIN rail mount.

Product Overview

The ABB 1SVR405650R1000 is a 1-pole miniature circuit breaker (MCB) from the S200 series. It is designed to provide reliable overcurrent and short-circuit protection for electrical circuits in a wide range of applications. This model features a 16A rated current, a C characteristic tripping curve, and a 6kA breaking capacity, making it suitable for protecting circuits with moderate inrush currents.

Technical Specifications

Parameter	Specification
Manufacturer	ABB AG
Series	S200 Series (System pro M compact)
Type	1SVR405650R1000
Product Type	Miniature Circuit Breaker (MCB)
Number of Poles	1P
Rated Current (In)	16 A
Rated Voltage (Ue)	240 V AC
Rated Frequency	50/60 Hz
Tripping Characteristic	C (5-10 In)
Breaking Capacity (Icn)	6 kA (IEC/EN 60898)
Energy Limiting Class	3
Mounting	DIN Rail 35 mm
Electrical Life	20,000 cycles
Mechanical Life	20,000 cycles
Ambient Temperature	-25 to 60 °C (-13 to 140 °F)
Connection	Screw clamp terminals
Terminal Capacity	Up to 25 mm² (flexible)
Dimensions (W x H x D)	18 × 89 × 70 mm (1 module)
Certifications	CE, cULus, IEC/EN 60898-1, CCC, KC

Key Features

C Characteristic Curve: Provides protection for circuits with moderate inrush currents (motors, transformers, lighting)
High Breaking Capacity: 6 kA ensures safe interruption of short-circuit faults
DIN Rail Mounting: Quick and secure installation on standard 35 mm rail
Screw Clamp Terminals: Ensures reliable connection for both solid and stranded conductors
Compact Design: 1 module width (18 mm) for space-efficient panel design
Clear Status Indication: Visual ON/OFF and tripped position indicator
Long Service Life: High electrical and mechanical durability
Global Standards Compliance: Certified for use worldwide

Applications

Circuit protection for general-purpose sockets and lighting in residential and commercial buildings
Protection of control circuits and small motors in industrial panels
Distribution boards in workshops and light industrial facilities
Any application requiring 16A circuit protection with C curve characteristic

Important Notes

The C characteristic trips at 5-10 times the rated current, providing a balance between overload and inrush tolerance.
This MCB is for AC circuits only.
Ensure the calculated prospective short-circuit current at the installation point does not exceed 6 kA.
Cable sizing and installation must comply with local wiring regulations and the breaker's terminal capacity.
For DC applications or different tripping characteristics (B, D, K, Z), other models in the S200 series are available.
