Endress+Hauser PMC71-MVE60 digital pressure transmitter. Cerabar S PMC71 series, 4-20mA HART, 0.05% accuracy, ceramic sensor, 316L wetted parts, -40 to 85°C.

Product Overview

The Endress+Hauser PMC71-MVE60​ is a digital gauge pressure transmitter​ from the Cerabar S PMC71 series. It utilizes a capacitive, oil-free ceramic sensor (Ceraphire)​ for highly stable measurement of liquids and gases, even under corrosive or abrasive conditions. This specific model (MVE60) is configured with a 4-20mA HART output, aluminum housing, and is designed for general process applications in chemical, water treatment, and industrial environments requiring high accuracy and reliability.

Technical Specifications (Measurement & Electrical)

Technical Specifications (Mechanical & Process)

Key Features

• Ceramic Sensor Immunity:​ The Ceraphire​ capacitive ceramic measuring cell is highly resistant to corrosion, abrasion, and vacuum conditions, ensuring long-term stability with minimal drift.

• High Turndown & Flexibility:​ 100:1 turndown ratio​ allows for significant adjustment of the measuring range in the field without sacrificing the high 0.05% accuracy.

• Integrated Diagnostics:​ Features comprehensive self-monitoring and HistoROM​ data storage for simplified maintenance and commissioning traceability.

• SIL Compliance:​ Designed to meet IEC 61508​ standards for SIL 2/3​ applications, making it suitable for safety instrumented systems.

Applications

• Process Pressure Monitoring:​ Continuous pressure measurement in pipelines, vessels, and reactors in chemical and petrochemical plants.

• Hydrostatic Level Measurement:​ Level calculation in open or closed tanks using the hydrostatic pressure method.

• Corrosive Media Handling:​ Ideal for aggressive or abrasive media where metal sensors might fail, thanks to the inert ceramic diaphragm.
