Endress+Hauser CUE22-A1A | pH/Conductivity Sensor Immersion Fitting, PVDF, G1"
Endress+Hauser CUE22-A1A immersion/flow-through fitting for pH, ORP & conductivity sensors. PVDF body, G1" process connection, Pg13.5 sensor port, max 6 bar, IP67.
Product Overview
The Endress+Hauser CUE22-A1A is a standard immersion and flow-through fitting designed for mounting pH, ORP, conductivity, and oxygen sensors (with Pg 13.5 process threads such as CPS11D, CPF81D, CLS21, COS41) into open tanks, basins, or pipe tees. It features a PVDF (polyvinylidene fluoride) body for excellent chemical resistance, a G1" female process connection, and a Pg 13.5 (≈27 mm) sensor port with compression seal. This version is configured for immersion mounting or installation in a flow cell (by-pass) and is widely used in water treatment, chemical dosing, and wastewater monitoring.
Technical Specifications (Process & Dimensions)
|
Parameter
|
Specification
|
|---|---|
|
Model / Order Code
|
CUE22-A1A
|
|
Product Type
|
Immersion / Insertion / Flow-Through Fitting
|
|
Sensor Compatibility
|
Sensors with Pg 13.5 (∅27 mm) process thread (e.g., CPS11D, CPF81D, CLS21-C1E4A, COS41)
|
|
Process Connection
|
G1" Female Thread (BSP Parallel)
|
|
Sensor Port
|
Pg 13.5 with compression seal ring (FKM/Viton or EPDM depending on variant)
|
|
Typical Immersion Length (L)
|
120 mm / 200 mm / 300 mm (order-specific — check suffix)
|
|
Max. Process Pressure
|
6 bar @ 20 °C
|
|
Max. Process Temperature
|
+80 °C (PVDF) / +130 °C (PPS version — check code)
|
Technical Specifications (Materials & Environmental)
|
Parameter
|
Specification
|
|---|---|
|
Body / Wetted Parts Material
|
PVDF (Polyvinylidene Fluoride) — excellent for halogens, acids, oxidants
|
|
Seal Material (Compression Ring)
|
Typically FKM (Viton) or EPDM (verify from full order code)
|
|
Mounting Style
|
Immersion (wall/tank flange) or In-line (with adapter tee)
|
|
Cable Gland (if applicable)
|
Not included — sensor connects directly
|
|
Protection Rating
|
IP67 (when sensor properly seated & tightened)
|
|
Weight (approx.)
|
0.25 – 0.45 kg (depending on length)
|
Key Features
-
Universal Sensor Fit: Accepts any Endress+Hauser sensor with Pg 13.5 thread (pH, ORP, conductivity, DO), making it a versatile platform across multiple measurement types.
-
Chemical Resistance: PVDF construction withstands aggressive media including chlorine, acids, and oxidizing agents — far superior to standard PVC or PP in many process waters.
-
Flexible Installation: Can be immersed directly into tanks via a mounting flange or installed in a by-pass flow cell for representative sampling from a pressurized line.
-
Secure Compression Seal: Integrated Pg 13.5 compression nut and seal ring ensure leak-tight sensor retention under rated pressure/temperature.
Applications
-
Wastewater Neutralization Basins: Immersion mounting of pH electrodes (CPS11D) for continuous pH monitoring.
-
Chemical Dosing Skids: In-line flow-through installation for conductivity (CLS21) or ORP (CPS12D) verification.
-
Cooling Tower / Boiler Blowdown: Sampling loop mounting for water quality sensors.
-
Potable Water Disinfection: Mounting of free chlorine (CCS50D) or ozone sensors in sample streams.
Note: For retractable / retractable-with-ball-valve versions, see CUE23 / CUE24 series. For hygienic (3-A / EHEDG) tri-clamp fittings, see CUE25 / CUE26 series.
