Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC

Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC
Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC

Large Image :  Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC Get Best Price

Product Details:
Place of Origin: DE
Brand Name: Endress+Hauser
Certification: ATEX
Model Number: FTL51B-29FJ20
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

Liquiphant M FTL51B level switch 316L

,

Vibrating fork level switch 3/4 NPT

,

Level switch SPST NO/NC 20-253V

Endress+Hauser FTL51B-29FJ20 | Liquiphant M FTL51B Vib. Fork Level Switch, 316L, 3/4" NPT, SPST NO/NC, 20–253V AC/DC
Endress+Hauser FTL51B-29FJ20 Liquiphant M compact vibrating fork level switch — 316L wetted parts, 3/4" NPT male process connection, SPST relay NO/NC output, 20–253 V AC/DC supply. For liquids, density ≥ 0.5 g/cm³, no calibration required.

Product Overview

The Endress+Hauser FTL51B-29FJ20​ is a compact Liquiphant M series vibrating fork (tuning fork) level switch​ for point-level detection of liquids in tanks, pipes, and sumps. The fork is made of 316L stainless steel​ with a 3/4" NPT male process connection, suitable for hygienic and industrial applications. It operates on the piezoelectric-driven resonance principle — the fork vibrates at its natural frequency (~1300 Hz) and stops vibrating when covered by liquid, triggering the SPST relay output (NO/NC, DPDT contact block style — option-dependent; -29FJ20 typically denotes 20–253 V AC/DC supply with relay output). No calibration or density adjustment is required; it ignores foam, conductivity, dielectric constant, and buildup. Suitable for overfill alarm, dry-run protection, and pump control in water/wastewater, chemical, and food & beverage industries.

Technical Specifications (Electrical & Output)

Parameter
Specification
Order Code​
FTL51B-29FJ20​ (Liquiphant M — Basic Version)
Series​
Endress+Hauser Liquiphant M (FTL51B Compact)
Measured Medium​
Liquids (conductive & non-conductive), min. density ≥ 0.5 g/cm³​
Switching Output​
1 × Changeover Contact (SPDT Relay / Dry Contact)​ — NO/NC configurable wiring
Supply Voltage​
20 … 253 V AC (50/60 Hz) / 20 … 253 V DC​ (Code "29" = universal AC/DC)
Contact Rating​
Max. 250 V AC / 3 A resistive (AC-15: 240 V / 3 A; DC-13: 24 V / 2 A)
Switching Delay​
< 1 s (typical)
Fail-Safe Mode​
Output de-energizes on power loss (switch to safe state — configurable via wiring)
Power Consumption​
≤ 2 VA

Technical Specifications (Mechanical & Process)

Parameter
Specification
Fork / Wetted Parts Material​
316L Stainless Steel (1.4404 / AISI 316L)​ — electropolished option per variant
Process Connection​
3/4" NPT Male Thread​ (integral — Code "J20" typical = 3/4" NPT)
Housing Material​
Die-cast Aluminum, polyester powder-coated (IP66/67, NEMA 4X)
Cable Entry​
1/2" NPT Female​ (threaded — blanking plug supplied; gland ordered separately)
Fork Length (Immersion)​
Fork prongs ≈ 40 mm (standard compact design — no extension)
Ambient Temperature​
-40 … +70 °C​
Process Temperature​
-40 … +150 °C​
Process Pressure​
-1 … +40 bar (-0.1 … +4.0 MPa)​
Degree of Protection​
IP66 / IP67​ (EN 60529), NEMA 4X
Approvals (Typical)​
CE, cCSAus General Purpose; optionally ATEX / IECEx Ex d / Ex ia — verify per suffix
Weight (Approx.)​
~1.3 kg

Key Features

  • No Calibration Required:​ Piezo-driven fork — immune to changing media properties (dielectric, conductivity, foam, viscosity within limits).
  • Universal AC/DC Supply (20–253 V):​ Single part covers both AC and DC panel supplies — simplifies spare stocking.
  • Compact Fork Design:​ Minimal intrusion into tank — suitable for small vessels, pump pits, and pipe tees.
  • Self-Monitoring Electronics:​ Continuous diagnostic check of fork oscillation — fails to safe state on fault (e.g. fork fouling beyond limits or electronics failure).
  • Robust 316L Construction:​ Corrosion-resistant wetted parts for water, wastewater, chemicals, and CIP/SIP-compatible processes.

Typical Applications

  • Pump Protection:​ Dry-run prevention in lift stations, booster sets, and chemical dosing skids.
  • Overfill / Low-Level Alarm:​ Tank high-level alert in chemical storage, food ingredient tanks, and IBC totes.
  • Sumps & Wet Wells:​ Sewage/storm-water wet well level switching — unaffected by turbulence or foam.
  • Process Skid Integration:​ Point-level detection in modular process units where compactness and no-adjustment operation are valued.
FTL51B is the compact (basic) Liquiphant M. For hygienic clamp/tri-clamp or larger fork extensions, see FTL50 / FTL51. The suffix "-29FJ20" typically decodes as: 29 = universal 20–253V AC/DC supply with relay output; F = housing/electronics version; J20 = 3/4" NPT male process connection. Exact option letter mapping may vary slightly by region — always cross-check the Endress+Hauser certificate of conformity / order confirmation for approval details (Ex / WHG / SIL). Many FTL51B variants are SIL 2 / SIL 3 capable per IEC 61508.
