Product Overview

The Yokogawa AAI143-H50 is a universal signal converter and isolator from the YTA/AAI series, designed for precise process signal conditioning. It accepts a wide variety of analog input signals from sensors like RTDs, thermocouples, and DC voltage/current sources. It performs linearization and conditioning, and outputs an isolated 4-20mA signal with HART digital communication for integration into modern control systems.

Technical Specifications

Key Features

• Universal Input:​ Configurable for RTD, thermocouple, or DC voltage/current signals

• Loop-Powered with HART:​ Simple 2-wire installation with digital communication capability

• High Accuracy & Isolation:​ Precise signal conversion with 1.5kV isolation

• Built-in Linearization:​ Converts non-linear RTD/T/C signals to linear 4-20mA output

• Flexible Configuration:​ Easy setup via local interface or HART communicator

• Rugged Design:​ Wide operating temperature range for industrial environments

• Compact DIN Rail Mount:​ Saves space in control panels and marshalling cabinets

• Optional Display:​ Local LCD for real-time process value and status

• Advanced Diagnostics:​ HART protocol provides access to device status and diagnostics

Applications

• Temperature measurement with RTD or thermocouple sensors

• Signal conversion and isolation for various process variables (pressure, level, flow)

• Upgrading legacy analog loops to include HART communication

• Interface between field sensors and DCS/PLC/SCADA systems

• Panel-mounted signal conditioning in control rooms and field enclosures

Important Notes

1. This is a 2-wire, loop-powered device; the power is derived from the 4-20mA output loop

2. Input type, range, and HART variables must be configured before use

3. For thermocouple inputs, ensure correct cold junction compensation

4. HART communication requires a minimum loop resistance (typically 250Ω)

5. Can be used as an isolator to eliminate ground loops in signal circuits
