Yokogawa AIP830-101EIMVESA Active Isolator | RTD, 4-20mA, IS, ATEX/IECEx

Large Image : Yokogawa AIP830-101EIMVESA Active Isolator | RTD, 4-20mA, IS, ATEX/IECEx Get Best Price

Product Details:

Place of Origin:	JP
Brand Name:	Yokogawa
Certification:	ATEX
Model Number:	AIP830-101EIMVESA
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

Yokogawa RTD active isolator

4-20mA signal isolator ATEX

IECEx certified active isolator

Yokogawa AIP830-101EIMVESA Active Isolator | RTD, 4-20mA, IS, ATEX/IECEx

Yokogawa AIP830-101EIMVESA isolator barrier specifications. RTD to 4-20mA, intrinsically safe, ATEX/IECEx certified, DIN rail mount.

Product Overview

The Yokogawa AIP830-101EIMVESA is a specific certified variant of the AIP830-101 active isolator safety barrier. It is designed for temperature measurement in hazardous areas, converting a signal from an RTD sensor into an isolated, intrinsically safe 4-20mA output for the control system. The suffix indicates its specific certification approvals for use in explosive atmospheres.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa Electric Corporation
Series	AIP Series (Intrinsic Safety Barriers)
Model	AIP830-101EIMVESA
Product Type	Active RTD Isolator Safety Barrier (Certified Variant)
Channel	Single Channel
Input Signal (Hazardous Area)	RTD (Pt100, 3-wire)
Output Signal (Safe Area)	4-20mA, Isolated
Power Supply	24V DC (±10%)
Isolation	1500V AC (Input to Output)
Accuracy	±0.1% of span
Safety Parameters (Hazardous Area)	Ui = 30V, Ii = 35mA, Pi = 0.9W, Ci = 0μF, Li = 10mH (typical)
RTD Excitation	Constant Current
Ambient Temperature Effect	±0.015% of span per °C
Operating Temperature	-20 to 60°C (-4 to 140°F)
Mounting	DIN Rail 35mm
Connection	Screw terminals
Certifications	ATEX, IECEx (as per model suffix 'EIMVESA')

Key Features

RTD to mA Conversion: Converts RTD resistance to a standard 4-20mA output signal
Intrinsic Safety Protection: Provides Ex ia IIC energy limitation for RTDs in hazardous areas
Active Isolation: Galvanic isolation between hazardous area sensor and safe area system
High Accuracy: ±0.1% accuracy for precise temperature measurement
Linearization: Built-in linearization for RTD input
Specific Certifications: Approved for use in hazardous locations per ATEX and IECEx standards
Compact DIN Rail Mount: Saves space in control cabinets
Easy Configuration: Adjustable for RTD range and calibration

Applications

Temperature measurement with RTD sensors in ATEX/IECEx Zone 0/1 hazardous areas
Interfacing RTDs in petrochemical, oil & gas, and chemical plants to safe area control systems
Signal isolation and conditioning for critical temperature loops requiring specific certification
Projects with mandatory ATEX or IECEx compliance for equipment

Important Notes

The RTD sensor in the hazardous area must have compatible Ex ia IIC certification
The system design must comply with entity concept using the specific safety parameters (Ui, Ii, Pi, Ci, Li)
Requires a separate 24V DC power supply for operation
Input is for 3-wire RTD (Pt100); verify sensor type and wiring
Installation must follow the certified control drawing and applicable hazardous area standards
