Yokogawa ATD5A-00 Wireless Temperature Transmitter | ISA100, Head-Mount, RTD

Large Image : Yokogawa ATD5A-00 Wireless Temperature Transmitter | ISA100, Head-Mount, RTD Get Best Price

Product Details:

Place of Origin:	JP
Brand Name:	Yokogawa
Certification:	ATEX
Model Number:	ATD5A-00
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

Yokogawa wireless temperature transmitter

ISA100 head-mount RTD transmitter

Yokogawa ATD5A-00 temperature sensor

Yokogawa ATD5A-00 Wireless Temperature Transmitter | ISA100, Head-Mount, RTD

Yokogawa ATD5A-00 wireless transmitter specifications. ISA100 Wireless, head-mount, RTD input, for temperature monitoring.

Product Overview

The Yokogawa ATD5A-00 is a head-mounted wireless temperature transmitter compatible with the ISA100 Wireless industrial network standard. It is designed for easy installation on thermowells or connection heads in the field, converting signals from RTD temperature sensors into digital data and transmitting it wirelessly to a gateway. This eliminates the need for field wiring, reducing installation costs in hard-to-reach or hazardous locations.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa Electric Corporation
Series	ISA100 Wireless Field Devices
Model	ATD5A-00
Product Type	Wireless Head-Mounted Temperature Transmitter
Wireless Standard	ISA100.11a (IEC 62734)
Input Sensor	RTD (Pt100, 3-wire)
Measurement Range	Depends on RTD sensor; typically -200 to 600°C (-328 to 1112°F)
Accuracy	±0.1% of reading or ±0.1°C (whichever is greater) + RTD sensor accuracy
Update Rate	Configurable (e.g., 1 second to several minutes)
Power Supply	Internal Lithium Battery (BR-2450A or equivalent)
Battery Life	Typically 5+ years (depends on update rate and environment)
Frequency Band	2.4 GHz ISM Band
Communication Range	Up to 200m line-of-sight (typical, depends on environment)
Mounting	Field Head-Mount (DIN B Connection)
Process Temperature	Limited by connected sensor/thermowell
Ambient Temperature	-40 to 85°C (-40 to 185°F)
Enclosure Rating	IP66 / NEMA 4X
Certifications	CE, cULus, ATEX, IECEx (for hazardous areas)

Key Features

Wireless ISA100.11a: Reliable, secure wireless communication for industrial networks
Head-Mount Design: Compact and robust for direct field installation
Long Battery Life: Multi-year operation reduces maintenance
Easy Installation: No field wiring required, significantly lowering installation cost
Hazardous Area Approval: Suitable for installation in classified areas
Robust Construction: IP66/NEMA 4X enclosure for harsh environments
Flexible Configuration: Update rate and other parameters configurable via the wireless network
Network Compatibility: Works with Yokogawa and other ISA100.11a compliant gateways

Applications

Wireless temperature monitoring in oil & gas, chemical, and power plants
Remote monitoring of equipment and processes in hard-to-wire locations
Temporary measurements for process optimization and testing
Adding measurement points to existing plants without running new cables
Monitoring in hazardous areas where wiring is complex or costly

Important Notes

Requires an ISA100 Wireless network infrastructure (e.g., Yokogawa AED5D-00 gateway)
The RTD sensor and thermowell must be purchased separately
Battery life is dependent on transmission interval and environmental conditions
Actual wireless range can be reduced by obstacles, metal structures, and interference
Configuration and diagnostics are performed wirelessly through the network manager

Yokogawa ATD5A-00 Wireless Temperature Transmitter | ISA100, Head-Mount, RTD 0
