Yokogawa AX01C-C010CH Electronic Controller | Temperature/PID, 1/4 DIN, Relay Output

Large Image : Yokogawa AX01C-C010CH Electronic Controller | Temperature/PID, 1/4 DIN, Relay Output Get Best Price

Product Details:

Place of Origin:	JP
Brand Name:	Yokogawa
Certification:	ATEX
Model Number:	AX01C-C010CH
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

Yokogawa AX01C temperature controller

1/4 DIN PID controller

relay output electronic controller

Yokogawa AX01C-C010CH Electronic Controller | Temperature/PID, 1/4 DIN, Relay Output

Yokogawa AX01C-C010CH controller specifications. 1/4 DIN temperature/PID controller, thermocouple input, relay output.

Product Overview

The Yokogawa AX01C-C010CH is a 1/4 DIN size, panel-mounted electronic controller designed primarily for temperature control applications. It features a digital display, accepts thermocouple inputs, and provides PID control with an electromechanical relay output for direct switching of heaters or contactors. It is a cost-effective solution for basic to medium-complexity process control loops in industrial ovens, furnaces, and environmental chambers.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa Electric Corporation
Series	UT/UTAdvanced Series (Panel Controllers)
Model	AX01C-C010CH
Product Type	1/4 DIN PID Temperature Controller
Panel Cutout	92 x 45 mm
Input Type	Thermocouple (Type C, specific to suffix)
Control Output 1	Relay (SPDT) - 250V AC, 5A (Resistive)
Control Output 2	Optional (Alarm Relay)
Control Action	PID with Self-Tuning (AT) / On-Off
Display	Dual 4-digit, 7-segment LED (PV & SV)
Control Period	1 to 100 seconds (adjustable)
Power Supply	100-240V AC, 50/60Hz
Number of Alarms	1 or 2 (assignable: High/Low/Deviation)
Communications	Optional (RS-485, etc.)
Ambient Temperature	0 to 55°C (32 to 131°F)
Front Panel Rating	IP66 (NEMA 4X)

Key Features

Compact 1/4 DIN Design: Saves panel space while providing full functionality
Dual LED Display: Shows Process Value (PV) and Set Value (SV) simultaneously
Advanced PID Control: Auto-tuning for optimal performance with minimal overshoot
Flexible Alarm: At least one assignable alarm function for process monitoring
Universal Power Supply: 100-240V AC for global use
Rugged Front Panel: IP66 rating for protection against dust and water spray
Easy Setup: Intuitive parameter configuration via front panel keys
Heater Break Alarm: Optional function for detecting heater failure

Applications

Temperature control for industrial ovens, furnaces, and dryers
Plastic processing machinery (injection molding, extruders)
Packaging machinery heat seal control
Food processing and cooking equipment
Environmental test chambers and incubators

Important Notes

The 'C010' in the model number typically specifies a Type C (W5Re/W26Re) thermocouple input. Verify sensor compatibility.
The relay output is for switching contactors or heaters directly; verify load current does not exceed 5A resistive.
Auto-tuning (AT) should be run after installation for optimal PID parameters.
Alarm function(s) must be configured (type and setpoint) for desired monitoring.
For communication or a second alarm output, optional modules may be required.
