Yokogawa AXG080 programmable module specifications. I/O expansion and logic module for UTAdvanced controllers, 8 digital I/O.

Product Overview

The Yokogawa AXG080 is a programmable function module designed for the UTAdvanced series of digital controllers. It provides additional input/output (I/O) capacity and logic control capabilities, expanding the functionality of the main controller. This module adds digital inputs and outputs, allowing for more complex sequencing, interlocking, and control logic alongside the primary control loops.

Technical Specifications

Key Features

• I/O Expansion:​ Adds 8 configurable digital I/O points to the main controller

• Programmable Logic:​ Enables creation of custom ladder logic programs for sequencing and interlocking

• Flexible Configuration:​ Each point can be individually configured as a digital input or output

• Seamless Integration:​ Directly mounts to and communicates with the main controller via internal bus

• Easy Programming:​ Configured using Yokogawa's dedicated setup software

• Space-Saving Design:​ Compact module that expands functionality without additional panel space

• Enhanced Control:​ Adds capabilities like timers, counters, and basic arithmetic operations

• Improved Automation:​ Allows for more complex machine control and process sequences

Applications

• Adding start/stop permissives and interlock logic to temperature control loops

• Controlling auxiliary devices (pumps, fans, solenoid valves) based on process conditions

• Implementing sequential batch steps in conjunction with the main controller's PID loops

• Creating custom alarm and shutdown sequences

• General-purpose machine automation and sequencing

Important Notes

1. Must be used with a compatible UTAdvanced series main controller (e.g., AXG4A, AX7)

2. The 8 I/O points are configurable as either inputs or outputs, but not a mix of analog and digital

3. Requires configuration software (e.g., Yokogawa YTA or dedicated configurator) for programming

4. The logic program executes within the main controller's scan cycle

5. Verify the main controller's maximum allowable number of expansion modules
