Product Overview

The Yokogawa AXG100-GG000BA1AH114B-NNNNNCH is a highly configurable, 1/8 DIN programmable controller from the UTAdvanced AXG100 series. It combines multi-loop PID control, programmable logic (ladder), and communication capabilities in a single compact unit. This specific configuration includes universal I/O, relay outputs, and extensive communication options, making it a powerful platform for complex machine and process control applications.

Technical Specifications

Key Features

• Integrated Platform:​ Combines continuous PID control, sequential logic, and communication in one device

• Compact 1/8 DIN Size:​ Saves significant panel space while offering advanced functionality

• Flexible I/O System:​ Scalable I/O via plug-in expansion modules (analog, digital, communication)

• Powerful Programming:​ Ladder logic for complex interlocking, sequencing, and calculations

• Advanced PID Control:​ Multiple auto-tuning modes and sophisticated control algorithms

• Extensive Communications:​ Built-in support for major industrial networks for easy integration

• High-Resolution Display:​ Clear display of process values, trends, and alarms

• Recipe Management:​ Supports multiple control recipes for batch processes

Applications

• Complex machine control (packaging, plastic processing, textile)

• Multi-zone temperature/pressure control systems with sequencing

• Small to medium batch process control

• Standalone control systems requiring both logic and PID loops

• As a smart remote I/O and control node in networked automation systems

Important Notes

1. The long model suffix defines the exact hardware configuration: I/O types, communication ports, power supply, and options

2. I/O capacity is expanded by adding specific AXG series I/O modules to the base unit

3. Requires configuration and programming software for setup

4. The number of PID loops and ladder logic capacity are fixed per model variant

5. Verify all suffix codes against the required I/O points, communication protocols, and power supply
