Yokogawa B9565AW power supply module specifications. For YS100/YS1000 controllers, 100-240V AC input, 5V/24V DC outputs.

Product Overview

The Yokogawa B9565AW is a dedicated power supply module designed for the YS100 and YS1000 series single-loop digital controllers. It converts a standard mains AC voltage into the regulated DC voltages required by the controller and its optional modules. This unit provides a reliable and integrated power solution, mounting directly to the DIN rail alongside the controller.

Technical Specifications

Key Features

• Dedicated Design:​ Specifically engineered for YS100/YS1000 controller compatibility

• Wide AC Input Range:​ 100-240V AC for global use

• Dual DC Outputs:​ Provides both 5V for the controller and 24V for accessories

• Integrated Solution:​ Mounts on the same DIN rail, creating a clean and compact setup

• Fuse Protection:​ Includes an input fuse for safety

• Easy Installation:​ Simple wiring with clear terminal markings

• Reliable Operation:​ Provides stable power for consistent controller performance

Applications

• Primary power source for YS100 or YS1000 series digital controllers

• Providing power for optional communication modules (e.g., RS-485, Ethernet) connected to the controller

• Powering auxiliary 24V DC devices in a small control loop (e.g., a solenoid valve) from the same supply

Important Notes

1. This power supply is specifically for the YS100/YS1000 controller series.

2. The 24V DC output has a limited current capacity; verify total load does not exceed its rating.

3. For applications requiring multiple controllers or higher 24V loads, a separate, larger capacity 24V DC power supply may be necessary.

4. Ensure correct wiring of AC line and neutral to the input terminals.

5. The fuse rating should not be changed; use only the specified replacement fuse.
