Yokogawa EJA110E-JFS5J-917NB Pressure Transmitter | 4-20mA+HART, Integral Mount, Orifice

Large Image : Yokogawa EJA110E-JFS5J-917NB Pressure Transmitter | 4-20mA+HART, Integral Mount, Orifice Get Best Price

Product Details:

Place of Origin:	JP
Brand Name:	Yokogawa
Certification:	ATEX
Model Number:	EJA110E-JFS5J-917NB
Document:	ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	Negotiable
Payment Terms:	T/T,XT,ALIPAY
Supply Ability:	100pcs per month

Contact Now

Detailed Product Description

Power Supply:

12-30 V DC (Two-wire)

Ambient Temperature:

-40°C To 80°C (-40°F To 176°F)

Electrical Rating:

General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification)

Certifications:

Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)

Highlight:

Yokogawa EJA110E pressure transmitter

4-20mA HART pressure transmitter

integral mount orifice transmitter

Yokogawa EJA110E-JFS5J-917NB Pressure Transmitter | 4-20mA+HART, Integral Mount, Orifice

Yokogawa EJA110E-JFS5J-917NB DP transmitter specifications. Integral mount for orifice flow, 4-20mA+HART, compact design.

Product Overview

The Yokogawa EJA110E-JFS5J-917NB is a differential pressure transmitter from the DPharp EJA-E series, configured for integral mounting with an orifice plate assembly. The "JFS5J" suffix indicates a compact, flangeless design that mounts directly between orifice flanges. It measures the DP generated by the orifice and provides a 4-20mA output with HART protocol, forming the core of a compact, primary flow element for liquid, gas, or steam measurement.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa Electric Corporation
Series	DPharp EJA-E Series
Model	EJA110E-JFS5J-917NB
Product Type	Integral Mount DP Transmitter (Orifice Flange)
Measurement	Differential Pressure (for flow)
Output Signal	4-20mA DC with HART Protocol, 2-wire
Power Supply	Loop-powered (10.5-42 V DC)
Mounting	Integral, between Orifice Flanges (Flangeless design)
Flange Rating	Typically ANSI 150# / 300# (defined by suffix)
Wetted Parts	316 SST (Standard)
Accuracy	±0.055% of span
Static Pressure Effect	±0.1% of URL per 10 MPa
Process Temperature	-40 to 120°C (-40 to 248°F)
Ambient Temperature	-40 to 85°C (-40 to 185°F)
Enclosure Rating	IP66 / NEMA 4X
Certifications	CE, cULus, ATEX, IECEx, SIL 2/3

Key Features

Ultra-Compact Integral Design: Mounts directly between orifice flanges, eliminating separate impulse lines and manifolds
High Accuracy DP Measurement: Silicon resonant sensor ensures reliable flow data
HART Communication: Enables remote configuration and multivariable access
Reduced Installation Cost: Eliminates need for tubing, valves, and fittings associated with remote mount transmitters
Robust & Reliable: Suitable for demanding process conditions
Self-Diagnostics: Built-in diagnostics for predictive maintenance
Global Approvals: Certified for use in hazardous areas

Applications

Flow measurement of liquids, gases, and steam using orifice plates
Energy and utility monitoring
Process flow measurement in oil & gas, chemical, and power generation
Applications where a space-saving, low-maintenance flow solution is critical

Important Notes

This transmitter is part of a flow measurement system; an orifice plate and mating flanges are required
The orifice plate must be sized and specified separately for the application
HART communication is used to access the DP value for flow calculation in a DCS/PLC
For steam or gas, temperature and pressure compensation are typically needed for mass/energy flow
The 'NB' suffix may indicate specific options like material or calibration
