Product Overview

The Yokogawa GX90YA-04-C1N-3N is a compact, panel-mounted data acquisition station (paperless recorder) from the GX/GP series. It is designed for continuous data logging, display, and analysis of process variables. This model features a 4-inch color touchscreen display, 4 universal analog input channels, and Ethernet communication, providing a versatile solution for monitoring and recording temperature, pressure, flow, and other signals.

Technical Specifications

Key Features

• Compact Touchscreen Interface:​ Intuitive operation and clear visualization of trends and data

• Universal Analog Inputs:​ Flexible connection for various sensor types (T/C, RTD, mA, V)

• Ethernet Connectivity:​ Enables data transfer, remote monitoring, and configuration

• Internal Data Logging:​ Stores trend and historical data on built-in flash memory

• Alarm Relays:​ Four configurable relay outputs for process alarm annunciation

• USB Port:​ For data backup, transfer, and firmware updates

• Mathematical Functions:​ Allows computation and recording of calculated values

• Robust Front Panel:​ IP65 rating for protection in industrial environments

Applications

• Continuous monitoring and recording of process variables (temp, pressure, etc.)

• Energy management and utility sub-metering data logging

• Equipment performance testing and validation

• Environmental chamber and oven monitoring

• Small-scale batch process data acquisition

Important Notes

1. The "04" indicates 4 analog input channels; the "C1N" suffix specifies the universal input type and other base features

2. The "3N" suffix typically denotes Ethernet communication and a specific power supply (100-240V AC)

3. Input type for each channel must be configured in the device settings

4. Recording interval and memory allocation are user-configurable

5. Relay outputs are for alarm signaling; external power is required to switch loads
