Yokogawa ISC40G-TG-T1-10 magmeter specifications. In-line electromagnetic flowmeter, 10-inch, PTFE lined, 4-20mA+HART output.

Product Overview

The Yokogawa ISC40G-TG-T1-10 is a full-bore, flanged magnetic flowmeter (magmeter) from the ADMAG series. Designed for conductive liquid flow measurement, it uses Faraday's Law of electromagnetic induction. This specific model is a 10-inch meter with a PTFE liner and titanium electrodes, making it suitable for corrosive or abrasive fluids. It provides a 4-20mA output with HART communication.

Technical Specifications

Key Features

• No Moving Parts:​ Maintenance-free operation with no pressure drop

• Wide Application:​ Suitable for conductive liquids including corrosive, abrasive, or slurry services

• High Accuracy:​ Unaffected by fluid density, viscosity, pressure, or temperature changes

• Bi-directional Measurement:​ Measures flow in both directions

• Empty Pipe Detection:​ Can be configured to detect no-flow conditions

• HART Communication:​ Enables remote configuration, diagnostics, and digital data access

• Robust Construction:​ PTFE liner and titanium electrodes for chemical resistance

Applications

• Water and wastewater flow measurement

• Chemical and acid flow in process lines

• Slurry and abrasive fluid flow in mining and pulp & paper

• Food and beverage processes (with appropriate sanitary liner/electrodes)

• General industrial conductive liquid flow

Important Notes

1. The liquid must have a minimum conductivity (typically ≥5 μS/cm)

2. The meter must be full at all times for accurate measurement

3. Requires proper grounding for accurate and safe operation

4. The transmitter (converter) is typically mounted separately from the sensor

5. Verify liner and electrode material compatibility with the specific process fluid
