Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output

Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output
Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output

Large Image :  Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output Get Best Price

Product Details:
Place of Origin: JP
Brand Name: Yokogawa
Certification: ATEX
Model Number: SC4AJ-S-AD-09-002-05-T1
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 12-30 V DC (Two-wire) Ambient Temperature: -40°C To 80°C (-40°F To 176°F)
Electrical Rating: General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification) Certifications: Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)
Highlight:

Yokogawa SC4AJ PID controller

,

1/4 DIN universal input controller

,

relay output process controller

Yokogawa SC4AJ-S-AD-09-002-05-T1 Controller | 1/4 DIN, PID, Universal Input, Relay Output

Yokogawa SC4AJ-S-AD-09-002-05-T1 controller specifications. 1/4 DIN single loop controller, universal input, relay output, PID control.

Product Overview

The Yokogawa SC4AJ-S-AD-09-002-05-T1 is a 1/4 DIN single-loop digital controller from the YS100 series. It is a versatile unit that can be configured for a variety of input types (thermocouple, RTD, voltage, current) and provides PID control with relay outputs. This specific configuration includes universal input, alarm relay, and a 1/2" NPT conduit connection, making it suitable for temperature, pressure, or flow control applications.

Technical Specifications

Parameter

Specification

Manufacturer​

Yokogawa Electric Corporation

Series​

YS100 Series (Single Loop Controller)

Model​

SC4AJ-S-AD-09-002-05-T1

Product Type​

1/4 DIN Single Loop PID Controller

Panel Cutout​

92 x 45 mm

Input Type​

Universal (Configurable: RTD, Thermocouple, DC Voltage/Current)

Control Output​

Relay (SPDT)

Alarm Output​

Relay (SPDT)

Control Action​

PID with Self-Tuning (AT)

Display​

Dual 4-digit, 7-segment LED (PV & SV)

Power Supply​

100-240V AC, 50/60Hz

Electrical Connection​

1/2" NPT Conduit

Communication​

Optional (requires additional module)

Ambient Temperature​

0 to 50°C (32 to 122°F)

Front Panel Rating​

IP66 (NEMA 4X)

Certifications​

CE, cULus

Key Features

  • Universal Input:​ Highly flexible; can be configured for various sensor types after installation

  • Dual Relay Outputs:​ One for control, one for alarm

  • Advanced PID Control:​ Auto-tuning for optimal performance

  • Compact 1/4 DIN Design:​ Saves panel space

  • Dual LED Display:​ Shows Process Value (PV) and Set Value (SV) simultaneously

  • Rugged Front Panel:​ IP66 rating for harsh environments

  • Easy Configuration:​ Setup via front panel keys

  • Expandable:​ Optional communication modules for RS-485, Ethernet, etc.

Applications

  • Temperature control for ovens, furnaces, and environmental chambers

  • Pressure or flow control in industrial processes

  • General-purpose single-loop PID control

  • Machine and equipment automation

Important Notes

  1. Input type and range must be configured based on the connected sensor

  2. Relay ratings are typically 250V AC, 3A resistive; verify for specific load

  3. For communication, an additional communication module (e.g., E7042UD) is required

  4. Auto-tuning (AT) should be performed after installation for optimal PID constants

  5. The "T1" in the suffix indicates the 1/2" NPT conduit connection
