Product Overview

The YOKOGAWA K9142TH is a high-temperature temperature sensor assembly from the K Series. It consists of an RTD (Pt100) sensor element housed within a heavy-duty threaded thermowell, specifically designed for elevated temperature industrial processes. The assembly enables accurate and reliable temperature measurement in demanding thermal environments while allowing sensor removal without process shutdown.

Technical Specifications

Key Features

• High-Temperature Capability:​ Designed for continuous operation up to 600°C

• Complete Assembly:​ Thermowell and high-temp RTD sensor integrated as a single unit

• Threaded Process Connection:​ 1/2" NPT for secure installation in standard fittings

• Removable Sensor Insert:​ Enables sensor replacement or recalibration without process interruption

• Heavy-Duty Construction:​ Robust thermowell material options for extreme thermal and pressure conditions

• Class A Accuracy:​ High-precision Pt100 element for reliable temperature measurement

• Fast Thermal Response:​ Optimized design for rapid temperature tracking

• Wide Application Range:​ Suitable for both high and low temperature extremes

Applications

• High-temperature process measurement in furnaces, ovens, and kilns

• Heat treatment and annealing processes

• Power generation: boiler flue gas, superheated steam

• Petrochemical and refinery cracking units

• Thermal fluid heating systems

• Industrial incineration and waste-to-energy plants

Important Notes

1. The exact insertion length, thermowell material, and connection type are defined by the full model suffix.

2. For service above 400°C, specialized thermowell materials (e.g., Inconel) and sensor construction are required.

3. The assembly includes the thermowell and Pt100 sensing element as an integrated unit.

4. A separate temperature transmitter or controller is required for signal conversion to standard outputs (e.g., 4-20mA).

5. Ensure thermowell material compatibility with process fluid composition and maximum operating temperature/pressure.
