YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration

YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration
YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration

Large Image :  YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration Get Best Price

Product Details:
Place of Origin: JP
Brand Name: YOKOGAWA
Certification: ATEX
Model Number: ZR22G-150-C-C-E-T-T-E-AF1SCTC-01
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 12-30 V DC (Two-wire) Ambient Temperature: -40°C To 80°C (-40°F To 176°F)
Electrical Rating: General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification) Certifications: Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)
Highlight:

Yokogawa ZR22G oxygen analyzer

,

Zirconia oxygen analyzer with HART

,

ATEX certified in-situ oxygen analyzer

YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 analyzer specifications. In-situ zirconia oxygen probe, 1500mm insertion, HART, ATEX, enhanced calibration system.

Product Overview

The YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 is an in-situ zirconia oxygen analyzer probe designed for continuous oxygen measurement in extreme high-temperature combustion processes. This model features a 1500mm (1.5 meter) extended insertion length, custom flange connection, HART communication, and ATEX hazardous area certification. The AF1SCTC-01 suffix specifies advanced calibration system hardware with traceable certification and enhanced documentation package for critical applications.

Technical Specifications

Parameter

Specification

Manufacturer​

YOKOGAWA Electric Corporation

Series​

ZR Series (Zirconia Oxygen Analyzers)

Model​

ZR22G-150-C-C-E-T-T-E-AF1SCTC-01

Product Type​

In-situ Zirconia Oxygen Probe

Measurement Principle​

Zirconia oxide ceramic cell

Measurement Range​

0.01 to 100% O₂ (vol %, dry basis)

Accuracy​

±0.5% of reading (above 1% O₂)

Repeatability​

±0.5% of reading

Response Time (90%)​

≤ 5 seconds

Probe Insertion Length​

1500 mm (59.05 inches)

Process Connection​

Special flange, high-temperature rated (defined by "C" suffix)

Process Gas Temperature​

0 to 700°C (32 to 1292°F)

Process Pressure​

-5 to +25 kPa (-0.7 to +3.6 psi)

Cell Heater​

Built-in ceramic heater (750°C operating temperature)

Output Signal​

4-20 mA DC with HART Protocol

Power Supply​

100-240V AC, 50/60 Hz

Calibration​

Fully automatic, integrated gas port with solenoid manifold

Calibration System​

AF1SCTC-01: 1-set automatic calibration unit with special traceable certification

Wetted Materials​

Stainless steel / Titanium, zirconia ceramic, alumina

Hazardous Area​

ATEX, IECEx (II 2 GD)

Ambient Temperature​

-20 to 55°C (-4 to 131°F)

Enclosure Rating​

IP66 / NEMA 4X

Certifications​

CE, cULus, ATEX, IECEx

Key Features

  • Ultra-Long 1500mm Probe:​ Engineered for very large ducts, deep furnace penetrations, and extreme environments

  • Special High-Temperature Flange:​ Custom flange configuration for non-standard or extreme temperature process connections

  • Dual HART & 4-20mA Output:​ Analog and digital communication for remote configuration and diagnostics

  • ATEX/IECEx Certified:​ Certified for hazardous areas (Zone 1/2, 21/22)

  • Enhanced Materials:​ Corrosion-resistant construction for aggressive flue gas compositions

  • Advanced Automatic Calibration:​ AF1SCTC-01 includes pre-assembled calibration gas unit with flow control and special NIST-traceable certification

  • **​ High-Temperature Performance:​ Reliable operation in process gas temperatures up to 700°C

  • Comprehensive Self-Diagnostics:​ Continuous cell impedance monitoring, heater control, and calibration validation

  • Special Traceable Certification:​ -01 suffix denotes enhanced quality documentation and calibration traceability

Applications

  • Ultra-large utility boilers (coal, oil, gas-fired)

  • Combined cycle gas turbine (CCGT) HRSG systems

  • Very large cement and lime rotary kilns

  • Glass melting furnaces with deep port requirements

  • Metallurgical reheat furnaces and soaking pits

  • Hazardous area installations requiring full ATEX/IECEx compliance

  • Critical process applications requiring enhanced calibration traceability

Important Notes

  1. Model Interpretation:​

    • 150​ = 1500mm insertion length

    • C-C​ = Special flange + calibration gas port

    • E​ = HART output

    • T-T​ = Titanium construction + ATEX certification

    • E​ = Enhanced electronics

    • AF1SCTC-01​ = Advanced flow system, 1-set calibration unit, special traceable certification

  2. Requires a compatible converter​ (ZR402G, ZR202S) for signal processing and power supply.

  3. AF1SCTC-01 calibration assembly​ includes solenoid valve unit, flowmeters, pressure regulators, and factory test report with traceability.

  4. 1500mm insertion requires​ mechanical support brackets and guide rails to prevent vibration and stress.

  5. Special flange rating​ must be verified against maximum process temperature and pressure.

  6. Installation must follow​ YOKOGAWA guidelines for minimum straight duct length and safe probe retraction.

  7. The zirconia cell is fragile​ — handle with extreme care during installation, operation, and maintenance.

YOKOGAWA ZR22G-150-C-C-E-T-T-E-AF1SCTC-01 Oxygen Analyzer | In-situ, Zirconia, 1500mm, HART, ATEX, Special Calibration 0
