YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX

YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX
YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX

Large Image :  YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX Get Best Price

Product Details:
Place of Origin: JP
Brand Name: YOKOGAWA
Certification: ATEX
Model Number: ZR402G-M-E-E-A
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 12-30 V DC (Two-wire) Ambient Temperature: -40°C To 80°C (-40°F To 176°F)
Electrical Rating: General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification) Certifications: Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)
Highlight:

Yokogawa ZR402G oxygen analyzer

,

Panel mount oxygen analyzer converter

,

ATEX certified oxygen analyzer 4-20mA

YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX

YOKOGAWA ZR402G-M-E-E-A converter specifications. Zirconia oxygen analyzer converter, panel mount, 4-20mA+HART output, ATEX certified.

Product Overview

The YOKOGAWA ZR402G-M-E-E-A is a microprocessor-based converter designed for use with ZR22G series zirconia oxygen analyzer probes. It supplies power to the probe, processes the oxygen concentration signal, and provides a 4-20mA DC analog output with superimposed HART digital communication. This model features ATEX hazardous area certification, panel mount configuration, and universal power supply.

Technical Specifications

Parameter

Specification

Manufacturer​

YOKOGAWA Electric Corporation

Series​

ZR Series (Zirconia Oxygen Analyzers)

Model​

ZR402G-M-E-E-A

Product Type​

Zirconia Oxygen Analyzer Converter

Compatible Probe​

ZR22G Series

Mounting​

Panel mount (1/4 DIN cutout: 92 × 92 mm)

Display​

Backlit LCD (oxygen %, cell temperature, heater voltage, diagnostics)

Output Signal​

4-20 mA DC with HART Protocol

Communication​

HART (Bell 202 FSK)

Probe Power Supply​

Integrated (heater and sensor drive)

Calibration​

Automatic or manual (external solenoid valve control)

Diagnostics​

Cell impedance, heater status, calibration validity, sensor drift

Hazardous Area​

ATEX, IECEx (II 2 GD)

Enclosure Rating​

IP66 / NEMA 4X (front panel)

Electrical Connection​

Rear terminal block

Ambient Temperature​

-20 to 55°C (-4 to 131°F)

Power Supply​

100-240V AC, 50/60 Hz (universal)

Weight​

Approx. 1.5 kg

Certifications​

CE, cULus, ATEX, IECEx

Key Features

  • ZR22G Probe Compatible:​ Dedicated converter for YOKOGAWA ZR22G series zirconia oxygen probes

  • HART Communication:​ 4-20mA analog output with superimposed HART digital protocol

  • Panel Mount Design:​ Standard 1/4 DIN cutout for control room or panel installation

  • ATEX/IECEx Certified:​ Suitable for installation in hazardous areas (Zone 1/2, 21/22)

  • Integrated Probe Power Supply:​ Directly powers ZR22G probe heater and sensor

  • Automatic Calibration Control:​ Built-in logic for external solenoid valve unit

  • Large Backlit LCD:​ Clear local display of oxygen concentration, cell temperature, and diagnostic messages

  • Dual-Range Capability:​ Configurable for two independent measurement ranges with automatic switching

  • **​ Multi-Language Display:​ Interface supports multiple languages

Applications

  • Control room or panel-mounted converter for ZR22G in-situ zirconia probes

  • Flue gas oxygen monitoring in boilers, furnaces, and process heaters

  • Combustion efficiency optimization in power plants and industrial facilities

  • Refineries, petrochemical, cement, and waste incineration plants

  • Hazardous area installations requiring ATEX/IECEx certified converters

Important Notes

  1. Model interpretation:​

    • ZR402G​ = Converter series

    • M​ = Panel mount (1/4 DIN)

    • E​ = HART output

    • E​ = ATEX/IECEx hazardous area certification

    • A​ = 100-240V AC universal power supply

  2. A compatible ZR22G series oxygen probe​ must be ordered separately.

  3. For automatic calibration, an external solenoid valve unit (e.g., ZR20H) and calibration gases are required.

  4. HART communication​ requires minimum loop resistance of 250Ω.

  5. Panel cutout​ dimension: 92 × 92 mm (+1.0/ -0.5 mm).

  6. Maximum cable length​ between converter and ZR22G probe must not exceed 100 meters (refer to instruction manual).

  7. The converter supports oxygen measurement​ in percent concentration (0.01 to 100% O₂).

YOKOGAWA ZR402G-M-E-E-A Oxygen Analyzer Converter | Panel Mount, 4-20mA, HART, ATEX 0
