YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head

YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head
YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head

Large Image :  YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head Get Best Price

Product Details:
Place of Origin: JP
Brand Name: YOKOGAWA
Certification: ATEX
Model Number: K9804JA
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 12-30 V DC (Two-wire) Ambient Temperature: -40°C To 80°C (-40°F To 176°F)
Electrical Rating: General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification) Certifications: Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)
Highlight:

YOKOGAWA RTD Pt100 temperature sensor

,

3-wire temperature sensor with connection head

,

1/2 NPT temperature sensor with warranty

YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head

YOKOGAWA K9804JA temperature sensor specifications. RTD Pt100 sensor assembly, 3-wire, 1/2" NPT, with aluminum connection head, general purpose.

Product Overview

The YOKOGAWA K9804JA is a general-purpose resistance temperature detector (RTD) sensor assembly designed for temperature measurement in industrial applications. It consists of a Pt100 sensor element housed in a protective thermowell with a 1/2" NPT threaded process connection. The assembly is terminated in a standard aluminum connection head, providing a protected junction for wiring to a temperature transmitter or indicator.

Technical Specifications

Parameter

Specification

Manufacturer​

YOKOGAWA Electric Corporation

Series​

K Series (Temperature Sensors)

Model​

K9804JA

Product Type​

RTD Sensor Assembly (with Thermowell and Connection Head)

Sensor Type​

Pt100, 3-wire

Accuracy Class​

Class A or Class B (model specific)

Process Connection​

1/2" NPT Male Thread

Thermowell Material​

316 Stainless Steel

Sensor Sheath Material​

316 Stainless Steel

Insertion Length​

Variable (model specific, e.g., 100mm, 150mm)

Process Temperature​

-200 to 500°C (-328 to 932°F)

Process Pressure​

Up to 10 MPa (1450 psi) (dependent on design)

Response Time​

τ₀.₆₃ < 10 seconds (typical)

Connection Head​

Aluminum, weatherproof

Terminal Connection​

Screw terminals within the head

Ambient Temperature (Head)​

-40 to 85°C (-40 to 185°F)

Certifications​

CE, cULus

Key Features

  • Pt100, 3-Wire:​ Provides good accuracy with lead resistance compensation

  • Complete Ready-to-Install Assembly:​ Includes sensor, thermowell, and connection head

  • 1/2" NPT Process Connection:​ Standard industrial fitting for easy installation

  • Removable Sensor Insert:​ Allows for field replacement or calibration without process shutdown

  • Robust Thermowell:​ Protects the sensor element from harsh process conditions

  • Weatherproof Connection Head:​ Protects wiring terminals from environmental factors

  • Wide Temperature Range:​ Suitable for diverse industrial applications

  • Direct Compatibility:​ Can be connected to most standard temperature transmitters

Applications

  • Temperature measurement in pipes, tanks, and vessels

  • Process industries: chemical, petrochemical, oil & gas

  • Power generation (water, steam lines)

  • HVAC and refrigeration systems

  • General industrial temperature monitoring

Important Notes

  1. The exact insertion length, accuracy class (A/B), and other options are defined by the full model suffix.

  2. This assembly includes the thermowell; the RTD sensor inside is typically field-replaceable.

  3. A separate temperature transmitter or indicator is required to process the RTD signal into a standard output (4-20mA, etc.).

  4. Ensure the thermowell material (316 SS) is compatible with the process media.

  5. Proper installation torque and sealing are required for the threaded connection to prevent leaks.

YOKOGAWA K9804JA Temperature Sensor | RTD Pt100, 3-Wire, 1/2" NPT, with Connection Head 0
