YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range

YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range
YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range

Large Image :  YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range Get Best Price

Product Details:
Place of Origin: JP
Brand Name: YOKOGAWA
Certification: ATEX
Model Number: WU10-V-S-05
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 12-30 V DC (Two-wire) Ambient Temperature: -40°C To 80°C (-40°F To 176°F)
Electrical Rating: General Purpose, Explosion-proof, Intrinsic Safety (depends On Certification) Certifications: Standard Models Include ATEX, IECEx, SIL 2 (consult Manual For Specific Ratings)
Highlight:

Yokogawa ultrasonic level sensor

,

non-contact level sensor 4-20mA

,

IP66 level sensor 5m range

YOKOGAWA WU10-V-S-05 Level Sensor | Ultrasonic, Non-Contact, 4-20mA, IP66, 5m Range

YOKOGAWA WU10-V-S-05 sensor specifications. Ultrasonic level sensor, non-contact, 4-20mA+HART, 5m range, IP66, for liquids and solids.

Product Overview

The YOKOGAWA WU10-V-S-05 is a non-contact ultrasonic level sensor designed for continuous level measurement of liquids and solids. It operates by emitting ultrasonic pulses and measuring the time for the echo to return, calculating the distance to the material surface. This model features a 5-meter measuring range, a 4-20mA output with HART communication, and a rugged IP66 housing suitable for outdoor and industrial environments.

Technical Specifications

Parameter

Specification

Manufacturer​

YOKOGAWA Electric Corporation

Series​

WU10 (Ultrasonic Level)

Model​

WU10-V-S-05

Product Type​

Non-contact Ultrasonic Level Sensor

Measuring Range​

0.25 to 5.0 m

Beam Angle​

8°

Accuracy​

±0.25% of range or ±3 mm, whichever is greater

Output Signal​

4-20 mA DC with HART Protocol

Power Supply​

10.5 to 30V DC (Loop powered) / 100-240V AC

Response Time​

1 second (adjustable)

Process Temperature​

-40 to 80°C (-40 to 176°F)

Ambient Temperature​

-40 to 80°C (-40 to 176°F)

Frequency​

50 kHz

Housing Material​

PBT plastic (sensor), aluminum (electronics housing)

Enclosure Rating​

IP66 / NEMA 4X

Mounting​

2" NPT thread or flange

Communication​

HART, PC configurator, local push buttons

Certifications​

CE, cULus, ATEX, IECEx

Key Features

  • Non-Contact Measurement:​ No moving parts, maintenance-free, suitable for corrosive or sticky media

  • 5m Range:​ Suitable for mid-sized tanks and silos

  • HART Communication:​ Remote configuration, calibration, and diagnostics

  • Wide Temperature Range:​ Operates in harsh environmental conditions

  • IP66 Housing:​ Dust-tight and protected against powerful water jets

  • Easy Setup:​ Intuitive local interface with push buttons and display

  • False Echo Suppression:​ Advanced software to ignore fixed tank obstructions

  • Dual Power Option:​ Available in loop-powered DC or AC supply variants

Applications

  • Continuous level measurement of water, chemicals, and fuels in storage tanks

  • Bulk solid level in silos (grains, plastics, powders)

  • Wastewater and process water level monitoring

  • Inventory management and control

Important Notes

  1. Performance can be affected by heavy foam, dust, vapor, or extreme turbulence.

  2. A minimum dead zone (approx. 0.25m) exists below the sensor; it cannot measure in this area.

  3. For AC-powered models, verify the specific suffix (e.g., WU10-V-S-05-A for AC).

  4. Proper mounting location is critical; avoid beams, agitators, or fill streams in the sound cone.

  5. The sensor requires periodic cleaning of the transducer face for optimal performance.
