YOKOGAWA UT130-RNAL Temperature Controller | 1/16 DIN, PID, R Type Thermocouple, Relay Output

YOKOGAWA UT130-RNAL Temperature Controller | 1/16 DIN, PID, R Type Thermocouple, Relay Output

YOKOGAWA UT130-RNAL controller specifications. 1/16 DIN temperature controller, R thermocouple input, relay output, PID control, compact.

Product Overview

The YOKOGAWA UT130-RNAL is a compact 1/16 DIN indicating controller from the UTAdvanced series. It is configured for temperature control with a specific R-type thermocouple input and a relay output. The controller provides PID control algorithm, a clear digital display, and is designed for space-constrained panels in applications such as small ovens, furnaces, and packaging machinery.

Technical Specifications

Key Features

• Ultra-Compact 1/16 DIN:​ Saves significant panel space

• R-Type Thermocouple Input:​ For high-temperature measurements

• Dual Relay Outputs:​ One for control, one for alarm

• PID with Self-Tuning:​ Automatic optimization of control parameters

• Dual LED Display:​ Shows Process Value and Set Value simultaneously

• IP66 Front Panel:​ Protected against dust and water spray

• Universal Power Supply:​ 100-240V AC for worldwide use

• Easy Setup:​ Intuitive front-panel operation

Applications

• Temperature control in small industrial ovens and furnaces

• Heat seal control in packaging machinery

• Plastic processing equipment

• Laboratory and testing equipment

• Any application requiring compact, reliable temperature control with an R-type thermocouple

Important Notes

1. The input is fixed for R-type thermocouples; ensure sensor compatibility.

2. Relay ratings are typically 250V AC, 3A resistive; verify compatibility with the load (contactor, heater).

3. The alarm relay can be configured for various functions (high/low limit, deviation).

4. For communication, an optional communication module (e.g., B9901AX00) is required.

5. Auto-tuning (AT) should be performed after installation to optimize PID constants.
