Product Overview

The YOKOGAWA UM33A-000-11LP is a 1/4 DIN indicating controller from the UM33A series, designed for temperature control. The "LP" suffix indicates a low-profile housing, reducing the depth behind the panel. It is configured for a specific thermocouple input type (defined by "000"), provides PID control with a relay output, and includes an alarm relay. It is suitable for space-constrained panels in ovens, furnaces, and packaging machinery.

Technical Specifications

Key Features

• Low-Profile Design:​ Reduced depth for shallow control panels

• Fixed Thermocouple Input:​ Pre-configured for a specific sensor type

• Dual Relay Outputs:​ One for control, one for alarm

• Compact 1/4 DIN Size:​ Standard panel footprint

• Dual LED Display:​ Shows Process Value and Set Value

• PID Control:​ For stable temperature regulation

• IP66 Front Panel:​ Protected against dust and water

• Universal Power Supply:​ 100-240V AC operation

Applications

• Temperature control in ovens, furnaces, and dryers with limited panel depth

• Plastic processing and packaging machinery

• Food processing equipment

• Environmental chambers

• Any application requiring a compact, shallow-depth temperature controller

Important Notes

1. The "000" suffix defines the specific thermocouple input type; verify compatibility with the sensor.

2. The "LP" low-profile design has a specific reduced depth; confirm it fits the available panel space.

3. Relay ratings are typically 250V AC, 3A resistive; check load compatibility.

4. The alarm relay is configurable for various functions.

5. For communication, an optional communication module must be added.
