YOKOGAWA SC210G-A-100-L015-05A Temperature Controller | 1/4 DIN, PID, Universal Input, Relay/SSR, RS485

YOKOGAWA SC210G-A-100-L015-05A Temperature Controller | 1/4 DIN, PID, Universal Input, Relay/SSR, RS485

YOKOGAWA SC210G-A-100-L015-05A controller specifications. 1/4 DIN temperature controller, universal input, dual relay output, RS485, for complex control.

Product Overview

The YOKOGAWA SC210G-A-100-L015-05A is a high-performance 1/4 DIN single-loop controller from the YS1000 series. The extensive suffix defines a complete configuration with universal input capability, dual relay outputs (likely for heating/cooling or control/alarm), and RS485 communication. The "L015" and "05A" segments specify advanced options such as a linear current output for valve control and specialized control functions. It is designed for demanding temperature and process control applications.

Technical Specifications

Key Features

• Universal Input:​ Accepts thermocouple, RTD, voltage, and current signals

• Dual Output Configuration:​ Two relay outputs or one relay + one linear current output for complex control strategies (e.g., heating + cooling, or control valve + alarm)

• RS485 Communication:​ Enables integration into Modbus networks for SCADA/DCS

• Linear Current Output (Option):​ Provides a 4-20mA signal for proportional control of I/P converters or valves

• Advanced PID & Functions:​ Includes fuzzy logic, adaptive tuning, and programmable events

• Heater Burnout Detection:​ Monitors heater current via external CT

• Compact 1/4 DIN Design:​ Standard size for industrial panels

• IP66 Front Panel:​ Suitable for harsh environments

Applications

• Advanced temperature control in industrial furnaces and ovens

• Processes requiring heating and cooling control (e.g., reactors, environmental chambers)

• Control of steam valves via I/P converters using the linear output

• Integration into plant-wide monitoring and control systems via Modbus

• Critical applications requiring heater monitoring and advanced diagnostics

Important Notes

1. The suffix A-100-L015-05A​ defines a specific advanced configuration. "L015" often indicates a linear current output option, and "05A" denotes special software functions.

2. Outputs are configurable; one may be set as a linear 4-20mA output for analog control.

3. Heater burnout detection requires an external current transformer (CT).

4. The RS485 interface uses Modbus RTU protocol; proper network addressing and termination are required.

5. This is an advanced controller; proper configuration of its numerous parameters is essential for optimal performance.
