VEGAPULS 69 | Radar Level Sensor for Continuous Measurement
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Highlight: | VEGAPULS 69 radar level sensor,continuous level measurement sensor,industrial radar level sensor |
||
|---|---|---|---|
VEGAPULS 69 | Radar Level Sensor for Continuous Measurement
Product Overview
The VEGAPULS 69 is a 80 GHz pulse radar sensor designed for continuous, non-contact level measurement of liquids, pastes, and slurries in industrial processes. Operating in the K-band frequency range, it offers high measurement precision, reliability in challenging conditions (vapor, dust, foam), and easy installation with a compact design.
Key Features
-
80 GHz (K-Band) Frequency: Provides a focused beam for precise measurement, minimizing interference from tank walls or internal structures.
-
Non-Contact Measurement: Ideal for corrosive, abrasive, or hygienic applications without wear.
-
High Signal Focus: Small antenna size (e.g., 1" or 2") suitable for small nozzles and vessels.
-
Robust Performance: Reliable in the presence of process noise, buildup, steam, or dust.
-
Easy Setup & Configuration: Simple menu-guided operation via display/keys or PC software (VEGA Tools).
-
Versatile Communication: Standard 4-20 mA/HART, with options for PROFIBUS PA, Foundation Fieldbus, or Modbus RS485.
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model |
VEGAPULS 69 |
|
Manufacturer |
VEGA Grieshaber KG |
|
Measuring Principle |
Pulse radar (80 GHz, K-Band) |
|
Measuring Range |
Up to 120 m (394 ft), model-dependent |
|
Process Connection |
Thread (e.g., G1½A, 1½" NPT) or Flange (e.g., DN50/2", 3") |
|
Antenna Size / Material |
e.g., 1" (PTFE) or 2" (PTFE, PP); flush designs available |
|
Process Temperature |
-40 to 200 °C (-40 to 392 °F) |
|
Process Pressure |
Up to 40 bar (580 psi), up to 100 bar (1450 psi) with seal |
|
Accuracy |
Typically ±2 mm (0.08") or 0.1% of measured value |
|
Power Supply |
2-wire: 10.5 - 36 V DC (4-20 mA/HART) |
|
Protection Rating |
IP66/67, NEMA 4X |
|
Certifications |
ATEX, IECEx, FM, CSA, SIL 2/3 |
|
Field of Application |
Liquids, pastes, slurries in chemical, power, water, food & beverage, etc. |
Applications
-
Level measurement in storage and process tanks (chemicals, water, wastewater).
-
Measurement in vessels with agitators, heating coils, or ladders.
-
Applications with foam, heavy vapor, or dust.
-
Hygienic applications in food, beverage, and pharmaceutical industries (with suitable antenna design).
Compliance & Certifications
-
Explosion Protection: ATEX, IECEx, FM, CSA
-
Functional Safety: SIL 2/3 according to IEC 61508/IEC 61511
-
Hygiene: EHEDG, 3-A (depending on model/antenna)
