Eaton DIL M25-10C Motor Protector | 25A, 10kA, 3-Pole, 480V AC, IEC/UL

Eaton DIL M25-10C Motor Protector | 25A, 10kA, 3-Pole, 480V AC, IEC/UL

Eaton DIL M25-10C MPCB specifications. 25A rated current, 3-pole, 10kA breaking capacity, adjustable overload. Motor protection circuit breaker.

Product Overview

The Eaton DIL M25-10C is a compact Motor Protection Circuit Breaker (MPCB) from the DIL M Series, designed for the protection and switching of three-phase motors. It integrates overload protection, short-circuit protection, and a manual switching mechanism in a single device. The "M25-10C" indicates a 25A rated current for motor protection with a 10kA breaking capacity, offering adjustable thermal and magnetic protection settings.

Technical Specifications

Key Features

• Integrated Motor Protection:​ Combines overload and short-circuit protection

• Manual Switching:​ Rotary handle for ON/OFF and isolation functions

• Adjustable Settings:​ Thermal and magnetic trip settings for precise motor matching

• Compact Design:​ Space-saving for control panel applications

• DIN Rail Mounting:​ Easy installation on standard 35mm DIN rail

• Trip-Free Mechanism:​ Contacts cannot be held closed during a fault

• Visual Indication:​ Clear ON/OFF/tripped position display

• Motor Isolation:​ Suitable for use as a manual motor isolator

• Add-on Accessories:​ Compatible with auxiliary contact blocks

• Global Standards:​ Complies with international IEC standards

Applications

• Protection of three-phase AC motors up to 25A

• Pump, fan, and compressor motor circuits

• Conveyor and material handling systems

• Machine tool motor protection

• HVAC equipment motor control

• Industrial control panels and motor control centers (MCCs)

Important Notes

1. Select based on motor full load current (FLC) and starting characteristics

2. Thermal setting should be adjusted to match motor FLC

3. Magnetic trip setting should accommodate motor starting current

4. For remote control, a separate contactor must be used downstream

5. Installation must comply with local electrical codes and standards
