Product Overview

The Eaton DIL M40C is a compact Motor Protection Circuit Breaker (MPCB) from the DIL M Series, designed for the protection and switching of three-phase motors. It integrates overload protection, short-circuit protection, and a manual switching mechanism in a single device. The "M40C" indicates a 40A rated current for motor protection, offering adjustable thermal and magnetic protection settings for reliable motor operation and fault interruption.

Technical Specifications

Key Features

• Integrated Motor Protection:​ Combines overload and short-circuit protection in one device

• Manual Switching:​ Rotary handle for ON/OFF control and motor isolation

• Adjustable Settings:​ Thermal and magnetic trip settings for precise motor matching

• Compact Design:​ Space-saving for control panel and MCC installations

• DIN Rail Mounting:​ Easy installation on standard 35mm DIN rail

• Trip-Free Mechanism:​ Ensures contacts open during fault conditions

• Visual Indication:​ Clear ON/OFF/tripped position display

• Motor Isolation:​ Can be used as a manual motor isolator switch

• Add-on Accessories:​ Compatible with auxiliary contact blocks

• Global Standards:​ Complies with international IEC standards

Applications

• Protection of three-phase AC motors up to 40A

• Pump, fan, and compressor motor circuits

• Conveyor and material handling systems

• Machine tool and industrial machinery motor protection

• HVAC and refrigeration system motors

• Motor control centers (MCCs) and industrial control panels

Important Notes

1. Select based on motor full load current (FLC) and starting characteristics

2. Thermal setting should be adjusted to match motor FLC

3. Magnetic trip setting should be set to accommodate motor starting current

4. For remote start/stop control, a separate contactor must be used downstream

5. Installation must comply with local electrical codes and standards
