Eaton SD32X timer relay specifications. Multi-function time delay relay, 32A SPDT output, DIN rail mount, 12-240V AC/DC, eight timing functions.

Product Overview

The Eaton SD32X is a high-capacity, multi-function solid state timer relay designed for demanding industrial control applications requiring direct switching of larger loads. It offers eight selectable timing functions and features a heavy-duty 32A SPDT output relay. With a universal supply voltage and a wide timing range, it is suitable for motor control, process sequencing, and other high-current timing applications.

Technical Specifications

Key Features

• High-Capacity Output:​ 32A SPDT relay for direct switching of motors and high-power loads

• 8 Timing Functions:​ On Delay, Off Delay, Interval, Single Shot, Repeat Cycle, Delayed Interval, Pulse Generator, Memory ON/OFF Delay

• Wide Voltage Range:​ Universal 12-240V AC/DC supply for flexible application

• Long Timing Range:​ From 0.1 seconds up to 100 hours

• Easy Configuration:​ Rotary switch for function, DIP switch for range, potentiometer for time

• Clear Indication:​ LEDs for power and output status

• Compact DIN Rail Mount:​ Saves space in control panels

• High Accuracy:​ ≤1% repeat accuracy for reliable timing

• Durable Design:​ Solid-state timing with robust relay output for high endurance

Applications

• Direct control of motors, pumps, and fans (within current rating)

• Conveyor and material handling system sequencing

• High-power lighting and heating control

• Process control and batch sequencing

• HVAC system control for large equipment

• General industrial automation requiring high-current switching

Important Notes

1. Timing function and range must be selected via the rotary and DIP switches before operation

2. The output relay rating is for resistive loads; significant derating applies for inductive loads (e.g., motors, contactors)

3. Ensure the supply voltage matches the selected AC/DC input range

4. For motor loads, verify the starting current does not exceed the relay's inrush capacity

5. Installation must comply with local electrical codes and standards
