Product Overview

The VEGA PS69.AXCSABHXAMKRX is a VEGAPULS 69 series 80 GHz frequency-modulated continuous wave (FMCW) radar level transmitter designed for precise level measurement of liquids, solids, and slurries. The extended model code defines a complete configuration with 80m measuring range, 4-20mA with HART output, 316L stainless steel housing, and specific process connection, cable, and certification options.

Technical Specifications

Key Features

• 80 GHz Technology:​ Narrow beam (3°) for superior focusing, ideal for tanks with obstacles

• Extended 80m Range:​ Suitable for very tall silos and large vessels

• High Accuracy:​ ±2 mm for precise inventory and process control

• HART Communication:​ Remote configuration, calibration, and diagnostics

• Robust Construction:​ 316L stainless steel housing for harsh industrial environments

• Dual Power Option:​ Loop powered DC or AC supply variants

• Intuitive Setup:​ Via push buttons, HART, or Bluetooth with VEGA Tools app

• Advanced Diagnostics:​ Echo curve display, signal quality indication, and device status monitoring

• Global Approvals:​ Comprehensive hazardous area and functional safety certifications

Applications

• High-accuracy level measurement of liquids, solids, and interfaces

• Tall silos and storage tanks (cement, grain, plastic pellets)

• Liquids in process vessels and reactors (chemicals, oil, water)

• Hazardous area applications (Zone 0/1, Zone 20/21)

• Custody transfer and inventory management

Important Notes

1. The model suffix AXCSABHXAMKRX​ specifies exact configuration: 80m range, 316L housing, specific process connection, electrical connection, cable, output, communication, and certifications.

2. 80 GHz provides excellent performance in vessels with agitators, nozzles, or other obstructions.

3. For safety applications (SIL2/3), specific configuration and assessment per the device's safety manual is required.

4. The transmitter supports both 4-20mA (HART)​ and optional PROFIBUS PA, FOUNDATION Fieldbus, or Ethernet-APL​ outputs (defined by suffix).

5. VEGACONNECT​ Bluetooth option enables wireless setup via smartphone/tablet (if included in suffix).

6. Proper mounting location​ is critical; refer to mounting guidelines for optimal performance.
